| General information | |
|---|---|
| Brand | Toyota |
| Model | Land Cruiser |
| Generation | Land Cruiser (J77) |
| Modification (Engine) | 4.2 D (HZJ77HV) (135 Hp) 4WD |
| Start of production | 1988 year |
| End of production | 1996 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Diesel |
| Weight-to-power ratio | 15.7 kg/Hp, 63.7 Hp/tonne |
| Weight-to-torque ratio | 7.5 kg/Nm, 134 Nm/tonne |
| Engine specs | |
| Power | 135 Hp @ 4000 rpm. |
| Power per litre | 32.4 Hp/l |
| Torque | 284 Nm @ 2200 rpm. 209.47 lb.-ft. @ 2200 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 1HZ |
| Engine displacement | 4163 cm3 254.04 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 94 mm 3.7 in. |
| Piston Stroke | 100 mm 3.94 in. |
| Compression ratio | 22.7:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 9.3 l 9.83 US qt | 8.18 UK qt |
| Engine oil specification |  Log in to see. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2120 kg 4673.8 lbs. |
| Max. weight | 2630 kg 5798.16 lbs. |
| Max load | 510 kg 1124.36 lbs. |
| Fuel tank capacity | 90 l 23.78 US gal | 19.8 UK gal |
| Dimensions | |
| Length | 4805 mm 189.17 in. |
| Width | 1790 mm 70.47 in. |
| Height | 1935 mm 76.18 in. |
| Wheelbase | 2730 mm 107.48 in. |
| Front track | 1455 mm 57.28 in. |
| Rear (Back) track | 1440 mm 56.69 in. |
| Ride height (ground clearance) | 215 mm 8.46 in. |
| Minimum turning circle (turning diameter) | 12.2 m 40.03 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Leaf spring |
| Rear suspension | Leaf spring |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
