Specifications: Toyota Land Cruiser (J80) 4.5 24V (FZJ80) (215 Hp) 4WD Automatic 1993, 1994, 1995, 1996

1990 Toyota Land Cruiser (J80) - Photo 1

Toyota Land Cruiser (J80) 4.5 24V (FZJ80) (215 Hp) 4WD Automatic – Full specifications
General information
Brand Toyota
Model Land Cruiser
Generation Land Cruiser (J80)
Modification (Engine) 4.5 24V (FZJ80) (215 Hp) 4WD Automatic
Start of production 1993 year
End of production 1996 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined 17.8 l/100 km
13.21 US mpg
15.87 UK mpg
5.62 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.6 sec
Acceleration 0 – 62 mph 12.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12 sec
Maximum speed 170 km/h
105.63 mph
Weight-to-power ratio 10.5 kg/Hp, 95.1 Hp/tonne
Weight-to-torque ratio 6.1 kg/Nm, 165 Nm/tonne
Engine specs
Power 215 Hp @ 4600 rpm.
Power per litre 48 Hp/l
Torque 373 Nm @ 3200 rpm.
275.11 lb.-ft. @ 3200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 1FZ-FE
Engine displacement 4477 cm3
273.2 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 100 mm
3.94 in.
Piston Stroke 95 mm
3.74 in.
Compression ratio 9:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 7.4 l
7.82 US qt | 6.51 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 13.4 l
14.16 US qt | 11.79 UK qt

Space, Volume and weights
Kerb Weight 2260 kg
4982.45 lbs.
Max. weight 2960 kg
6525.68 lbs.
Max load 700 kg
1543.24 lbs.
Trunk (boot) space – minimum 830 l
29.31 cu. ft.
Trunk (boot) space – maximum 1370 l
48.38 cu. ft.
Fuel tank capacity 95 l
25.1 US gal | 20.9 UK gal
Dimensions
Length 4820 mm
189.76 in.
Width 1930 mm
75.98 in.
Height 1860 mm
73.23 in.
Wheelbase 2850 mm
112.2 in.
Front track 1595 mm
62.8 in.
Rear (Back) track 1600 mm
62.99 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Dependent spring suspension with anti-roll bar
Rear suspension dependent spring suspension, Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Cone worm with recirculation balls
Power steering Hydraulic Steering
Tires size 275/70 R16
Wheel rims size 8J x 16
