| General information | |
|---|---|
| Brand | Toyota |
| Model | Land Cruiser Prado |
| Generation | Land Cruiser Prado (J120) |
| Modification (Engine) | 3.4 V6 (185 Hp) 4WD ECT-E |
| Start of production | 2002 year |
| End of production | 2004 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 8 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 10.5 kg/Hp, 94.9 Hp/tonne |
| Weight-to-torque ratio | 6.6 kg/Nm, 150.8 Nm/tonne |
| Engine specs | |
| Power | 185 Hp @ 4800 rpm. |
| Power per litre | 54.8 Hp/l |
| Torque | 294 Nm @ 3600 rpm. 216.84 lb.-ft. @ 3600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 5VZ-FE |
| Engine displacement | 3378 cm3 206.14 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 93.5 mm 3.68 in. |
| Piston Stroke | 82 mm 3.23 in. |
| Compression ratio | 9.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 5.2 l 5.49 US qt | 4.58 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1950-1990 kg 4299.01 – 4387.2 lbs. |
| Max. weight | 2430 kg 5357.23 lbs. |
| Max load | 440-480 kg 970.03 – 1058.22 lbs. |
| Trunk (boot) space – minimum | 620 l 21.9 cu. ft. |
| Trunk (boot) space – maximum | 1850 l 65.33 cu. ft. |
| Fuel tank capacity | 87 l 22.98 US gal | 19.14 UK gal |
| Dimensions | |
| Length | 4715 mm 185.63 in. |
| Width | 1875 mm 73.82 in. |
| Height | 1855-1870 mm 73.03 – 73.62 in. |
| Wheelbase | 2790 mm 109.84 in. |
| Front track | 1575 mm 62.01 in. |
| Rear (Back) track | 1575 mm 62.01 in. |
| Ride height (ground clearance) | 220 mm 8.66 in. |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 4 gears, automatic transmission ECT-E |
| Front suspension | Double wishbone |
| Rear suspension | Rigid axle suspension, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 265/65 R17 |
| Wheel rims size | 7.5J x 17 |
