Specifications: Toyota Land Cruiser Prado (J150, facelift 2013) 3-door 3.0 D-4D (190 Hp) 4WD Automatic 2013, 2014, 2015

2013 Toyota Land Cruiser Prado (J150, facelift 2013) 3-door - Photo 1

Toyota Land Cruiser Prado (J150, facelift 2013) 3-door 3.0 D-4D (190 Hp) 4WD Automatic – Full specifications
General information
Brand Toyota
Model Land Cruiser Prado
Generation Land Cruiser Prado (J150, facelift 2013) 3-door
Modification (Engine) 3.0 D-4D (190 Hp) 4WD Automatic
Start of production 2013 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban (NEDC) 9.6 l/100 km
24.5 US mpg
29.43 UK mpg
10.42 km/l
Fuel consumption (economy) – extra urban (NEDC) 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel consumption (economy) – combined (NEDC) 7.9 l/100 km
29.77 US mpg
35.76 UK mpg
12.66 km/l
CO2 emissions (NEDC) 209 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.7 sec
Acceleration 0 – 62 mph 11.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.1 sec
Maximum speed 175 km/h
108.74 mph
Emission standard Euro 5
Weight-to-power ratio 10.5 kg/Hp, 95 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 210 Nm/tonne
Engine specs
Power 190 Hp @ 3400 rpm.
Power per litre 63.7 Hp/l
Torque 420 Nm @ 1600-3000 rpm.
309.78 lb.-ft. @ 1600-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 1KD-FTV
Engine displacement 2982 cm3
181.97 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 103 mm
4.06 in.
Compression ratio 15:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 13.1 l
13.84 US qt | 11.53 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2000 kg
4409.25 lbs.
Max. weight 2600 kg
5732.02 lbs.
Max load 600 kg
1322.77 lbs.
Trunk (boot) space – minimum 381 l
13.45 cu. ft.
Trunk (boot) space – maximum 1434 l
50.64 cu. ft.
Fuel tank capacity 87 l
22.98 US gal | 19.14 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 3000 kg
6613.87 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 120 kg
264.55 lbs.
Dimensions
Length 4505 mm
177.36 in.
Width 1885 mm
74.21 in.
Height 1830 mm
72.05 in.
Wheelbase 2450 mm
96.46 in.
Front track 1585 mm
62.4 in.
Rear (Back) track 1585 mm
62.4 in.
Front overhang 915 mm
36.02 in.
Rear overhang 1140 mm
44.88 in.
Ride height (ground clearance) 205 mm
8.07 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Approach angle 32°
Departure angle 26°
Ramp-over (brakeover) angle 25°
Climb angle 42°
Wading depth 700 mm
27.56 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Coil spring, Double wishbone, Transverse stabilizer
Rear suspension Rigid axle suspension, Transverse stabilizer, Air Suspension – Optional
Front brakes Ventilated discs, 338×32 mm
Rear brakes Ventilated discs, 312×18 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 265/65 R17; 265/60 R18
Wheel rims size 7.5J x 17; 7.5J x 18
