Specifications: Toyota Land Cruiser Prado (J150, facelift 2017) 3-door 2.8 D-4D (177 Hp) 4WD 2017, 2018, 2019, 2020, 2021, 2022, 2023

2017 Toyota Land Cruiser Prado (J150, facelift 2017) 3-door - Photo 1

Toyota Land Cruiser Prado (J150, facelift 2017) 3-door 2.8 D-4D (177 Hp) 4WD – Full specifications
General information
Brand Toyota
Model Land Cruiser Prado
Generation Land Cruiser Prado (J150, facelift 2017) 3-door
Modification (Engine) 2.8 D-4D (177 Hp) 4WD
Start of production 2017 year
End of production October, 2023 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – combined 7.2 l/100 km
32.67 US mpg
39.23 UK mpg
13.89 km/l
CO2 emissions 190 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.1 sec
Acceleration 0 – 62 mph 12.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.5 sec
Maximum speed 175 km/h
108.74 mph
Emission standard Euro 6
Weight-to-power ratio 11.7 kg/Hp, 85.7 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 203.4 Nm/tonne
Engine specs
Power 177 Hp @ 3400 rpm.
Power per litre 64.2 Hp/l
Torque 420 Nm @ 1400-2600 rpm.
309.78 lb.-ft. @ 1400-2600 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 1GD-FTV
Engine displacement 2755 cm3
168.12 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 92 mm
3.62 in.
Piston Stroke 103.6 mm
4.08 in.
Compression ratio 15.6:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7.7 l
8.14 US qt | 6.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10.1 l
10.67 US qt | 8.89 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2065 kg
4552.55 lbs.
Max. weight 2600 kg
5732.02 lbs.
Max load 535 kg
1179.47 lbs.
Trunk (boot) space – minimum 381 l
13.45 cu. ft.
Trunk (boot) space – maximum 1434 l
50.64 cu. ft.
Fuel tank capacity 87 l
22.98 US gal | 19.14 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 3000 kg
6613.87 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 120 kg
264.55 lbs.
Dimensions
Length 4395 mm
173.03 in.
Width 1855 mm
73.03 in.
Height 1830 mm
72.05 in.
Wheelbase 2450 mm
96.46 in.
Front track 1585 mm
62.4 in.
Rear (Back) track 1585 mm
62.4 in.
Front overhang 975 mm
38.39 in.
Rear overhang 970 mm
38.19 in.
Ride height (ground clearance) 205 mm
8.07 in.
Approach angle 31°
Departure angle 26°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Dependent, multi-link spring with telescopic shock absorbers
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 265/65 R17; 265/60 R18; 265/55 R19
Wheel rims size 7.5J x 17; 7.5J x 18; 7.5J x 19
