Specifications: Toyota Land Cruiser Prado (J90, facelift 2000) 3-door 2.7 16V (150 Hp) 4WD ECT 2000, 2001, 2002

2000 Toyota Land Cruiser Prado (J90, facelift 2000) 3-door - Photo 1

Toyota Land Cruiser Prado (J90, facelift 2000) 3-door 2.7 16V (150 Hp) 4WD ECT – Full specifications
General information
Brand Toyota
Model Land Cruiser Prado
Generation Land Cruiser Prado (J90, facelift 2000) 3-door
Modification (Engine) 2.7 16V (150 Hp) 4WD ECT
Start of production 2000 year
End of production 2002 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 3
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 11.6 kg/Hp, 86.2 Hp/tonne
Weight-to-torque ratio 7.4 kg/Nm, 135.1 Nm/tonne
Engine specs
Power 150 Hp @ 4800 rpm.
Power per litre 55.7 Hp/l
Torque 235 Nm @ 4000 rpm.
173.33 lb.-ft. @ 4000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 3RZ-FE
Engine displacement 2693 cm3
164.34 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 95 mm
3.74 in.
Piston Stroke 95 mm
3.74 in.
Compression ratio 9.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 5.4 l
5.71 US qt | 4.75 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10 l
10.57 US qt | 8.8 UK qt

Space, Volume and weights
Kerb Weight 1740 kg
3836.04 lbs.
Max. weight 2015 kg
4442.31 lbs.
Max load 275 kg
606.27 lbs.
Trunk (boot) space – minimum 450 l
15.89 cu. ft.
Trunk (boot) space – maximum 836 l
29.52 cu. ft.
Fuel tank capacity 90 l
23.78 US gal | 19.8 UK gal
Dimensions
Length 4255 mm
167.52 in.
Width 1820 mm
71.65 in.
Height 1880 mm
74.02 in.
Wheelbase 2370 mm
93.31 in.
Front track 1505 mm
59.25 in.
Rear (Back) track 1510 mm
59.45 in.
Ride height (ground clearance) 230 mm
9.06 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Approach angle 37°
Departure angle 28°
Ramp-over (brakeover) angle 32°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission ECT
Front suspension Coil spring, Double wishbone, Transverse stabilizer
Rear suspension Rigid axle suspension, Coil spring
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/80 R16
