| General information | |
|---|---|
| Brand | Toyota |
| Model | Matrix |
| Generation | Matrix (E130) |
| Modification (Engine) | 1.8i 16V (124 Hp) AWD |
| Start of production | 2002 year |
| End of production | 2007 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.7 l/100 km 27.04 US mpg 32.47 UK mpg 11.49 km/l |
| Fuel consumption (economy) – extra urban | 7.4 l/100 km 31.79 US mpg 38.17 UK mpg 13.51 km/l |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 178 km/h 110.6 mph |
| Weight-to-power ratio | 9.8 kg/Hp, 102.1 Hp/tonne |
| Weight-to-torque ratio | 7.5 kg/Nm, 132.5 Nm/tonne |
| Engine specs | |
| Power | 124 Hp @ 6000 rpm. |
| Power per litre | 69.1 Hp/l |
| Torque | 161 Nm @ 4200 rpm. 118.75 lb.-ft. @ 4200 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 1ZZ-FE |
| Engine displacement | 1794 cm3 109.48 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79 mm 3.11 in. |
| Piston Stroke | 91.5 mm 3.6 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 3.7 l 3.91 US qt | 3.26 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.5 l 6.87 US qt | 5.72 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1215 kg 2678.62 lbs. |
| Trunk (boot) space – minimum | 617 l 21.79 cu. ft. |
| Trunk (boot) space – maximum | 1507 l 53.22 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 4350 mm 171.26 in. |
| Width | 1775 mm 69.88 in. |
| Height | 1540 mm 60.63 in. |
| Wheelbase | 2600 mm 102.36 in. |
| Front track | 1505 mm 59.25 in. |
| Rear (Back) track | 1480 mm 58.27 in. |
| Minimum turning circle (turning diameter) | 9.8 m 32.15 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/55 R16 |
