| General information | |
|---|---|
| Brand | Toyota |
| Model | Matrix |
| Generation | Matrix (E140) |
| Modification (Engine) | S 2.4 (160 Hp) Automatic |
| Start of production | 2008 year |
| End of production | 2014 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 13.5 l/100 km 17.42 US mpg 20.92 UK mpg 7.41 km/l |
| Fuel consumption (economy) – extra urban | 9.7 l/100 km 24.25 US mpg 29.12 UK mpg 10.31 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 8.6 kg/Hp, 115.7 Hp/tonne |
| Weight-to-torque ratio | 6.1 kg/Nm, 162.7 Nm/tonne |
| Engine specs | |
| Power | 160 Hp @ 5600 rpm. |
| Power per litre | 67.7 Hp/l |
| Torque | 225 Nm @ 4000 rpm. 165.95 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 2AZ-FE |
| Engine displacement | 2362 cm3 144.14 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88.5 mm 3.48 in. |
| Piston Stroke | 96 mm 3.78 in. |
| Compression ratio | 9.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, VVT-i |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.7 l 6.02 US qt | 5.02 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1383 kg 3048.99 lbs. |
| Trunk (boot) space – minimum | 560 l 19.78 cu. ft. |
| Trunk (boot) space – maximum | 1398 l 49.37 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Dimensions | |
| Length | 4394 mm 172.99 in. |
| Width | 1765 mm 69.49 in. |
| Height | 1549 mm 60.98 in. |
| Wheelbase | 2601 mm 102.4 in. |
| Front track | 1519 mm 59.8 in. |
| Rear (Back) track | 1521 mm 59.88 in. |
| Ride height (ground clearance) | 135 mm 5.31 in. |
| Minimum turning circle (turning diameter) | 10.8 m 35.43 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Disc, 295 mm |
| Rear brakes | Disc, 277 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/55 R16 89H |
| Wheel rims size | 16 |
