Specifications: Toyota Previa (CR) 2.2 TD (100 Hp) 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000

1991 Toyota Previa (CR) - Photo 1

Toyota Previa (CR) 2.2 TD (100 Hp) – Full specifications
General information
Brand Toyota
Model Previa
Generation Previa (CR)
Modification (Engine) 2.2 TD (100 Hp)
Start of production 1992 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 8
Doors 4
Performance specs
Fuel consumption (economy) – urban 11 l/100 km
21.38 US mpg
25.68 UK mpg
9.09 km/l
Fuel consumption (economy) – extra urban 6 l/100 km
39.2 US mpg
47.08 UK mpg
16.67 km/l
Fuel Type Diesel
Maximum speed 160 km/h
99.42 mph
Weight-to-power ratio 17.2 kg/Hp, 58.1 Hp/tonne
Weight-to-torque ratio 8 kg/Nm, 125.6 Nm/tonne
Engine specs
Power 100 Hp @ 4200 rpm.
Power per litre 45.8 Hp/l
Torque 216 Nm @ 2600 rpm.
159.31 lb.-ft. @ 2600 rpm.
Engine layout Middle, Longitudinal
Engine displacement 2184 cm3
133.28 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 94 mm
3.7 in.
Compression ratio 22:1
Number of valves per cylinder 2
Fuel injection system Precombustion chamber injection
Engine aspiration Turbocharger
Valvetrain OHC

Space, Volume and weights
Kerb Weight 1720 kg
3791.95 lbs.
Trunk (boot) space – minimum 670 l
23.66 cu. ft.
Trunk (boot) space – maximum 1782 l
62.93 cu. ft.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Dimensions
Length 4765 mm
187.6 in.
Width 1800 mm
70.87 in.
Height 1780 mm
70.08 in.
Wheelbase 2860 mm
112.6 in.
Front track 1560 mm
61.42 in.
Rear (Back) track 1550 mm
61.02 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Spring Strut
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/65 R15
