Specifications: Toyota Prius III (ZVW30) 1.8 (136 Hp) Plug-in Hybrid e-CVT 2012, 2013, 2014, 2015

2010 Toyota Prius III (ZVW30) - Photo 1

Toyota Prius III (ZVW30) 1.8 (136 Hp) Plug-in Hybrid e-CVT – Full specifications
General information
Brand Toyota
Model Prius
Generation Prius III (ZVW30)
Modification (Engine) 1.8 (136 Hp) Plug-in Hybrid e-CVT
Start of production 2012 year
End of production 2015 year
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Body type Liftback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined 2.1 l/100 km
112.01 US mpg
134.51 UK mpg
47.62 km/l
CO2 emissions 49 g/km
Fuel Type Petrol / electricity
Acceleration 0 – 100 km/h 10.8 sec
Acceleration 0 – 62 mph 10.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.3 sec
Maximum speed 180 km/h
111.85 mph
Emission standard Euro 5
Weight-to-power ratio 10.5 kg/Hp, 95.4 Hp/tonne
Weight-to-torque ratio 6.9 kg/Nm, 145.3 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 4.4 kWh
Battery voltage 207.2 V
Battery technology Lithium-ion (Li-Ion)
Battery weight 76 kg
167.55 lbs.
Battery location Under the trunk
All-electric range 25 km
15.53 mi
Average Energy consumption 5.2 kWh/100 km

8.37 kWh/100 mi
403 MPGe
19.2 km/kWh
11.9 mi/kWh
Max speed (electric) 85 km/h

52.82 mph
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor power 82 Hp
Electric motor Torque 207 Nm

152.68 lb.-ft.
Electric motor location Integrated into the transmission
Electric motor type Synchronous
System power 136 Hp
System torque 207 Nm
152.68 lb.-ft.
Internal combustion engine specs
Power 99 Hp @ 5200 rpm.
Power per litre 55.1 Hp/l
Torque 142 Nm @ 4000 rpm.
104.73 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code 2ZR-FXE
Engine displacement 1798 cm3
109.72 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 88.3 mm
3.48 in.
Compression ratio 13:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, VVT-i
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1425-1450 kg
3141.59 – 3196.7 lbs.
Max. weight 1840 kg
4056.51 lbs.
Max load 390-415 kg
859.8 – 914.92 lbs.
Trunk (boot) space – minimum 443 l
15.64 cu. ft.
Trunk (boot) space – maximum 1543 l
54.49 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Max. roof load 75 kg
165.35 lbs.
Dimensions
Length 4480 mm
176.38 in.
Width 1745 mm
68.7 in.
Height 1490 mm
58.66 in.
Wheelbase 2700 mm
106.3 in.
Front track 1525 mm
60.04 in.
Rear (Back) track 1520 mm
59.84 in.
Front overhang 925 mm
36.42 in.
Rear overhang 855 mm
33.66 in.
Drag coefficient (Cd) 0.25
Minimum turning circle (turning diameter) 11.2 m
36.75 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent type McPherson
Rear suspension Torsion
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
