Specifications: Toyota RAV4 EV I (BEA11) 3-door 25.9 kWh (61 Hp) 1997, 1998, 1999, 2000, 2001, 2002, 2003

Toyota RAV4 EV I (BEA11) 3-door 25.9 kWh (61 Hp) – Full specifications
General information
Brand	Toyota
Model	RAV4
Generation	RAV4 EV I (BEA11) 3-door
Modification (Engine)	25.9 kWh (61 Hp)
Start of production	1997 year
End of production	2003 year
Powertrain Architecture	BEV (Electric Vehicle)
Body type	SUV
Seats	4
Doors	3
Performance specs
Fuel Type	Electricity
Maximum speed	125 km/h 77.67 mph
Weight-to-power ratio	23.9 kg/Hp, 41.8 Hp/tonne
Electric cars and hybrids specs
Gross battery capacity	25.9 kWh
All-electric range	200 km 124.27 mi
Electric motor 1
Electric motor power	61 Hp @ 2600 rpm.
Electric motor Torque	165 Nm @ 2600 rpm. 121.7 lb.-ft. @ 2600 rpm.
System power	61 Hp

Space, Volume and weights
Kerb Weight	1460 kg 3218.75 lbs.
Max. weight	1720 kg 3791.95 lbs.
Max load	260 kg 573.2 lbs.
Dimensions
Length	3695 mm 145.47 in.
Width	1695 mm 66.73 in.
Height	1620 mm 63.78 in.
Wheelbase	2200 mm 86.61 in.
Drivetrain, brakes and suspension specs
Drive wheel	Front wheel drive
Number of gears and type of gearbox	1 gears, automatic transmission
Tires size	195/80 R16
Wheel rims size	6.5J x 16
