Specifications: Toyota RAV4 IV 2.2 D-4D (150 Hp) 4WD 2012, 2013, 2014, 2015

2013 Toyota RAV4 IV - Photo 1

Toyota RAV4 IV 2.2 D-4D (150 Hp) 4WD – Full specifications
General information
Brand Toyota
Model RAV4
Generation RAV4 IV
Modification (Engine) 2.2 D-4D (150 Hp) 4WD
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.7 l/100 km
35.11 US mpg
42.16 UK mpg
14.93 km/l
Fuel consumption (economy) – extra urban 5 l/100 km
47.04 US mpg
56.5 UK mpg
20 km/l
Fuel consumption (economy) – combined 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
CO2 emissions 147 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.6 sec
Acceleration 0 – 62 mph 9.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.1 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 5
Engine specs
Power 150 Hp @ 3600 rpm.
Power per litre 67.2 Hp/l
Torque 340 Nm @ 2000-2800 rpm.
250.77 lb.-ft. @ 2000-2800 rpm.
Engine layout Front, Transverse
Engine Model/Code 2AD-FTV
Engine displacement 2231 cm3
136.14 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 96 mm
3.78 in.
Compression ratio 15.7:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.9 l
6.23 US qt | 5.19 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.3 l
7.71 US qt | 6.42 UK qt
Engine systems Particulate filter

Space, Volume and weights
Max. weight 2220 kg
4894.26 lbs.
Trunk (boot) space – minimum 547 l
19.32 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Max. roof load 85 kg
187.39 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4570 mm
179.92 in.
Width 1845 mm
72.64 in.
Height 1660 mm
65.35 in.
Wheelbase 2660 mm
104.72 in.
Front track 1570 mm
61.81 in.
Rear (Back) track 1570 mm
61.81 in.
Drag coefficient (Cd) 0.314
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/65 R17
Wheel rims size 7J x 17
