Specifications: Toyota RAV4 IV 2.5 (176 Hp) AWD ECT-i 2012, 2013, 2014, 2015

2013 Toyota RAV4 IV - Photo 1

Toyota RAV4 IV 2.5 (176 Hp) AWD ECT-i – Full specifications
General information
Brand Toyota
Model RAV4
Generation RAV4 IV
Modification (Engine) 2.5 (176 Hp) AWD ECT-i
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 10.7 l/100 km
21.98 US mpg
26.4 UK mpg
9.35 km/l
Fuel consumption (economy) – extra urban 8.1 l/100 km
29.04 US mpg
34.87 UK mpg
12.35 km/l
Fuel Type Petrol (Gasoline)
Emission standard ULEV-II
Weight-to-power ratio 9.1 kg/Hp, 109.3 Hp/tonne
Weight-to-torque ratio 6.9 kg/Nm, 144.7 Nm/tonne
Engine specs
Power 176 Hp @ 6000 rpm.
Power per litre 70.6 Hp/l
Torque 233 Nm @ 4100 rpm.
171.85 lb.-ft. @ 4100 rpm.
Engine layout Front, Transverse
Engine Model/Code 2AR-FE
Engine displacement 2494 cm3
152.19 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 90 mm
3.54 in.
Piston Stroke 98 mm
3.86 in.
Compression ratio 10.4:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.4 l
4.65 US qt | 3.87 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.8 l
7.19 US qt | 5.98 UK qt

Space, Volume and weights
Kerb Weight 1610 kg
3549.44 lbs.
Max. weight 2087 kg
4601.05 lbs.
Max load 477 kg
1051.6 lbs.
Trunk (boot) space – minimum 1087 l
38.39 cu. ft.
Trunk (boot) space – maximum 2078 l
73.38 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Permitted trailer load with brakes (12%) 680 kg
1499.14 lbs.
Dimensions
Length 4569 mm
179.88 in.
Width 1844 mm
72.6 in.
Height 1661 mm
65.39 in.
Wheelbase 2659 mm
104.69 in.
Front track 1570 mm
61.81 in.
Rear (Back) track 1570 mm
61.81 in.
Ride height (ground clearance) 160 mm
6.3 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Approach angle 29°
Departure angle 22°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, automatic transmission ECT-i
Front suspension Independent type McPherson, Transverse stabilizer
Rear suspension Double wishbone, Transverse stabilizer, Trailing arm, Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/65 R17
Wheel rims size 7J x 17
