Specifications: Toyota Sienna III (facelift 2018) 3.5 V6 (296 Hp) Automatic 2018, 2019, 2020

2018 Toyota Sienna III (facelift 2018) - Photo 1

Toyota Sienna III (facelift 2018) 3.5 V6 (296 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Sienna
Generation Sienna III (facelift 2018)
Modification (Engine) 3.5 V6 (296 Hp) Automatic
Start of production 2018 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7-8
Doors 5
Performance specs
Fuel consumption (economy) – urban 12.4 l/100 km
18.97 US mpg
22.78 UK mpg
8.06 km/l
Fuel consumption (economy) – extra urban 8.7 l/100 km
27.04 US mpg
32.47 UK mpg
11.49 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 6.8 kg/Hp, 147.3 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 177.7 Nm/tonne
Engine specs
Power 296 Hp @ 6600 rpm.
Power per litre 84.6 Hp/l
Torque 357 Nm @ 4700 rpm.
263.31 lb.-ft. @ 4700 rpm.
Engine layout Front, Transverse
Engine Model/Code 2GR-FKS
Engine displacement 3500 cm3
213.58 cu. in.
Number of cylinders 6
Engine configuration V-engine
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, VVT-i
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.5 l
12.15 US qt | 10.12 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2009-2093 kg
4429.09 – 4614.28 lbs.
Trunk (boot) space – minimum 1107 l
39.09 cu. ft.
Trunk (boot) space – maximum 4248 l
150.02 cu. ft.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Permitted trailer load with brakes (12%) 1588 kg
3500.94 lbs.
Dimensions
Length 5095 mm
200.59 in.
Width 1984 mm
78.11 in.
Height 1750-1796 mm
68.9 – 70.71 in.
Wheelbase 3030 mm
119.29 in.
Front track 1720 mm
67.72 in.
Rear (Back) track 1720 mm
67.72 in.
Ride height (ground clearance) 157-165 mm
6.18 – 6.5 in.
Drag coefficient (Cd) 0.30-0.31
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 8 gears, automatic transmission ECT-i
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/60 R17; 235/55 R18
Wheel rims size 17; 18
