Specifications: Toyota Sprinter Carib 1.6i (110 Hp) 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002

Toyota Sprinter Carib 1.6i (110 Hp) – Full specifications
General information
Brand	Toyota
Model	Sprinter
Generation	Sprinter Carib
Modification (Engine)	1.6i (110 Hp)
Start of production	1995 year
End of production	2002 year
Powertrain Architecture	Internal Combustion engine
Body type	Station wagon (estate)
Seats	5
Doors	5
Performance specs
Fuel Type	Petrol (Gasoline)
Weight-to-power ratio	9.9 kg/Hp, 100.9 Hp/tonne
Weight-to-torque ratio	7.5 kg/Nm, 133 Nm/tonne
Engine specs
Power	110 Hp @ 6000 rpm.
Power per litre	69.3 Hp/l
Torque	145 Nm @ 4800 rpm. 106.95 lb.-ft. @ 4800 rpm.
Engine layout	Front, Transverse
Engine displacement	1587 cm³ 96.84 cu. in.
Number of cylinders	4
Engine configuration	Inline
Cylinder Bore	81 mm 3.19 in.
Piston Stroke	77 mm 3.03 in.
Compression ratio	9.5:1
Number of valves per cylinder	4
Fuel injection system	Multi-port manifold injection
Engine aspiration	Naturally aspirated engine
Valvetrain	DOHC

Space, Volume and weights
Kerb Weight	1090 kg 2403.04 lbs.
Fuel tank capacity	50 l 13.21 US gal \| 11 UK gal
Dimensions
Length	4360 mm 171.65 in.
Width	1690 mm 66.54 in.
Height	1490 mm 58.66 in.
Wheelbase	2465 mm 97.05 in.
Front track	1460 mm 57.48 in.
Rear (Back) track	1440 mm 56.69 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel	Front wheel drive
Number of gears and type of gearbox	5 gears, manual transmission
Front brakes	Ventilated discs
Rear brakes	Drum
Tires size	185/60 R14
Wheel rims size	5.5J x 14
