Specifications: Toyota Town Ace 2.0 TD (97 Hp) 4WD Automatic 1992, 1993, 1994, 1995, 1996

Toyota Town Ace 2.0 TD (97 Hp) 4WD Automatic – Full specifications
General information
Brand	Toyota
Model	Town Ace
Generation	Town Ace
Modification (Engine)	2.0 TD (97 Hp) 4WD Automatic
Start of production	1992 year
End of production	1996 year
Powertrain Architecture	Internal Combustion engine
Body type	Minivan
Seats	5
Doors	4
Performance specs
Fuel consumption (economy) – urban	9.4 l/100 km 25.02 US mpg 30.05 UK mpg 10.64 km/l
Fuel Type	Diesel
Weight-to-power ratio	15.4 kg/Hp, 65.1 Hp/tonne
Weight-to-torque ratio	7.8 kg/Nm, 128.9 Nm/tonne
Engine specs
Power	97 Hp @ 4000 rpm.
Power per litre	44.4 Hp/l
Torque	192 Nm @ 2200 rpm. 141.61 lb.-ft. @ 2200 rpm.
Engine layout	Front, Transverse
Engine displacement	2184 cm³ 133.28 cu. in.
Number of cylinders	4
Engine configuration	Inline
Cylinder Bore	86 mm 3.39 in.
Piston Stroke	94 mm 3.7 in.
Compression ratio	22.6:1
Number of valves per cylinder	2
Fuel injection system	Precombustion chamber injection
Engine aspiration	Turbocharger
Valvetrain	OHC

Space, Volume and weights
Kerb Weight	1490 kg 3284.89 lbs.
Fuel tank capacity	60 l 15.85 US gal \| 13.2 UK gal
Dimensions
Length	4360 mm 171.65 in.
Width	1685 mm 66.34 in.
Height	1825 mm 71.85 in.
Wheelbase	2230 mm 87.8 in.
Front track	1440 mm 56.69 in.
Rear (Back) track	1385 mm 54.53 in.
Drivetrain, brakes and suspension specs
Drive wheel	All wheel drive (4×4)
Number of gears and type of gearbox	4 gears, automatic transmission
Front suspension	Transverse stabilizer
Rear suspension	Transverse stabilizer
Front brakes	Ventilated discs
Rear brakes	Drum
Tires size	175/80 R14
Wheel rims size	14
