Specifications: Toyota Tundra I Double Cab (facelift 2002) SR5 4.7i V8 (282 Hp) 4×4 Automatic 2005, 2006

2003 Toyota Tundra I Double Cab (facelift 2002) - Photo 1

Toyota Tundra I Double Cab (facelift 2002) SR5 4.7i V8 (282 Hp) 4×4 Automatic – Full specifications
General information
Brand Toyota
Model Tundra
Generation Tundra I Double Cab (facelift 2002)
Modification (Engine) SR5 4.7i V8 (282 Hp) 4×4 Automatic
Start of production 2005 year
End of production 2006 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 15.6 l/100 km
15.08 US mpg
18.11 UK mpg
6.41 km/l
Fuel consumption (economy) – extra urban 13 l/100 km
18.09 US mpg
21.73 UK mpg
7.69 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 8 kg/Hp, 125.2 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 195.8 Nm/tonne
Engine specs
Power 282 Hp @ 5400 rpm.
Power per litre 60.5 Hp/l
Torque 441 Nm @ 3400 rpm.
325.26 lb.-ft. @ 3400 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 2UZ-FE
Engine displacement 4664 cm3
284.61 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 94 mm
3.7 in.
Piston Stroke 84 mm
3.31 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 6.2 l
6.55 US qt | 5.46 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.7 l
12.36 US qt | 10.29 UK qt

Space, Volume and weights
Kerb Weight 2252 kg
4964.81 lbs.
Max. weight 2994 kg
6600.64 lbs.
Max load 742 kg
1635.83 lbs.
Fuel tank capacity 100 l
26.42 US gal | 22 UK gal
Permitted trailer load with brakes (12%) 2948 kg
6499.23 lbs.
Dimensions
Length 5845 mm
230.12 in.
Width 2014 mm
79.29 in.
Height 1889 mm
74.37 in.
Wheelbase 3271 mm
128.78 in.
Front track 1673 mm
65.87 in.
Rear (Back) track 1709 mm
67.28 in.
Ride height (ground clearance) 302 mm
11.89 in.
Minimum turning circle (turning diameter) 14.3 m
46.92 ft.
Approach angle 26°
Departure angle 23°
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, automatic transmission ECT
Front suspension Double wishbone
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 265/65 R17
Wheel rims size 7.5J x 17
