| General information | |
|---|---|
| Brand | Toyota |
| Model | Tundra |
| Generation | Tundra I Regular Cab (facelift 2002) |
| Modification (Engine) | 4.0i (236 Hp) |
| Start of production | 2005 year |
| End of production | 2006 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 8 kg/Hp, 125.1 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 191.3 Nm/tonne |
| Engine specs | |
| Power | 236 Hp @ 5200 rpm. |
| Power per litre | 59.7 Hp/l |
| Torque | 361 Nm @ 4000 rpm. 266.26 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 1GR-FE |
| Engine displacement | 3956 cm3 241.41 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 94 mm 3.7 in. |
| Piston Stroke | 95 mm 3.74 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 10.4 l 10.99 US qt | 9.15 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1887 kg 4160.12 lbs. |
| Trunk (boot) space – maximum | 2625 l 92.7 cu. ft. |
| Fuel tank capacity | 100 l 26.42 US gal | 22 UK gal |
| Permitted trailer load with brakes (12%) | 2358 kg 5198.5 lbs. |
| Dimensions | |
| Length | 5545 mm 218.31 in. |
| Width | 1910 mm 75.2 in. |
| Height | 1796 mm 70.71 in. |
| Wheelbase | 3259 mm 128.31 in. |
| Front track | 1681 mm 66.18 in. |
| Rear (Back) track | 1648 mm 64.88 in. |
| Ride height (ground clearance) | 269 mm 10.59 in. |
| Minimum turning circle (turning diameter) | 13.6 m 44.62 ft. |
| Approach angle | 27° |
| Departure angle | 23° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Double wishbone |
| Rear suspension | Leaf spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 245/70 R16; 265/70 R16; 265/65 R17 |
| Wheel rims size | 7.0J x 16; 7.5J x 17 |
