Specifications: Toyota Tundra III CrewMax Standard Bed 3.5 V6 i-FORCE (389 Hp) 4×2 ECT-i 2021, 2022, 2023, 2024, 2025

2022 Toyota Tundra III CrewMax Standard Bed - Photo 1

Toyota Tundra III CrewMax Standard Bed 3.5 V6 i-FORCE (389 Hp) 4×2 ECT-i – Full specifications
General information
Brand Toyota
Model Tundra
Generation Tundra III CrewMax Standard Bed
Modification (Engine) 3.5 V6 i-FORCE (389 Hp) 4×2 ECT-i
Start of production September, 2021 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 13.1 l/100 km
17.96 US mpg
21.56 UK mpg
7.63 km/l
Fuel consumption (economy) – extra urban 10.2 l/100 km
23.06 US mpg
27.69 UK mpg
9.8 km/l
Fuel consumption (economy) – combined 11.8 l/100 km
19.93 US mpg
23.94 UK mpg
8.47 km/l
Fuel Type Petrol (Gasoline)
Emission standard LEV-III
Weight-to-power ratio 6.2 kg/Hp, 160.1 Hp/tonne
Weight-to-torque ratio 3.7 kg/Nm, 267.2 Nm/tonne
Engine specs
Power 389 Hp @ 5200 rpm.
Power per litre 112.9 Hp/l
Torque 649 Nm @ 2400 rpm.
478.68 lb.-ft. @ 2400 rpm.
Engine layout Front, Longitudinal
Engine Model/Code V35A-FTS
Engine displacement 3445 cm3
210.23 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 85.5 mm
3.37 in.
Piston Stroke 100 mm
3.94 in.
Compression ratio 10.4:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Twin-Turbo, Intercooler
Valvetrain DOHC, Dual VVT-i
Engine oil capacity 7.3 l
7.71 US qt | 6.42 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12.4 l
13.1 US qt | 10.91 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2429-2479 kg
5355.03 – 5465.26 lbs.
Max. weight 3171-3270 kg
6990.86 – 7209.12 lbs.
Max load 742-791 kg
1635.83 – 1743.86 lbs.
Fuel tank capacity 85 l
22.45 US gal | 18.7 UK gal
Permitted trailer load with brakes (12%) 5112 kg
11270.03 lbs.
Permitted towbar download 519 kg
1144.2 lbs.
Dimensions
Length 6238 mm
245.59 in.
Width 2037 mm
80.2 in.
Height 1981 mm
77.99 in.
Wheelbase 4006 mm
157.72 in.
Front track 1737 mm
68.39 in.
Rear (Back) track 1737 mm
68.39 in.
Ride height (ground clearance) 236 mm
9.29 in.
Drag coefficient (Cd) 0.36
Minimum turning circle (turning diameter) 15.2 m
49.87 ft.
Approach angle 21°
Departure angle 24°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 10 gears, automatic transmission ECT-i
Front suspension Double wishbone, Transverse stabilizer
Rear suspension Rigid axle suspension, Coil spring
Front brakes Ventilated discs, 353 mm
Rear brakes Ventilated discs, 345 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 265/70 R18; 265/60 R20
Wheel rims size 8J x 18; 8J x 20
