Specifications: Toyota Yaris ATIV (XP150) 1.2 (86 Hp) CVT 2017, 2018, 2019, 2020

2017 Toyota Yaris ATIV (XP150) - Photo 1

Toyota Yaris ATIV (XP150) 1.2 (86 Hp) CVT – Full specifications
General information
Brand Toyota
Model Yaris
Generation Yaris ATIV (XP150)
Modification (Engine) 1.2 (86 Hp) CVT
Start of production 2017 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel Type Petrol (Gasoline)
Engine specs
Power 86 Hp @ 6000 rpm.
Power per litre 71.8 Hp/l
Torque 108 Nm @ 4000 rpm.
79.66 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code 3NR-FE
Engine displacement 1197 cm3
73.05 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 72.5 mm
2.85 in.
Piston Stroke 72.5 mm
2.85 in.
Compression ratio 11.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, D-VVT-i
Engine oil capacity 3.4 l
3.59 US qt | 2.99 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 4.2 l
4.44 US qt | 3.7 UK qt

Space, Volume and weights
Fuel tank capacity 42 l
11.1 US gal | 9.24 UK gal
Dimensions
Length 4425 mm
174.21 in.
Width 1730 mm
68.11 in.
Height 1475 mm
58.07 in.
Wheelbase 2550 mm
100.39 in.
Front track 1470 mm
57.87 in.
Rear (Back) track 1460 mm
57.48 in.
Ride height (ground clearance) 133 mm
5.24 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission CVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension independent torsion suspension
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Tires size 185/60 R15
Wheel rims size 15
