Specifications: Toyota Yaris III 1.0 VVT-i (69 Hp) 2011, 2012, 2013, 2014

2012 Toyota Yaris III - Photo 1

Toyota Yaris III 1.0 VVT-i (69 Hp) – Full specifications
General information
Brand Toyota
Model Yaris
Generation Yaris III
Modification (Engine) 1.0 VVT-i (69 Hp)
Start of production 2011 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – extra urban 4.2 l/100 km
56 US mpg
67.26 UK mpg
23.81 km/l
Fuel consumption (economy) – combined 4.8 l/100 km
49 US mpg
58.85 UK mpg
20.83 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 15.3 sec
Acceleration 0 – 62 mph 15.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 14.5 sec
Maximum speed 155 km/h
96.31 mph
Emission standard Euro 5
Weight-to-power ratio 13.8 kg/Hp, 72.6 Hp/tonne
Weight-to-torque ratio 10.2 kg/Nm, 97.9 Nm/tonne
Engine specs
Power 69 Hp @ 6000 rpm.
Power per litre 69.1 Hp/l
Torque 93 Nm @ 3600 rpm.
68.59 lb.-ft. @ 3600 rpm.
Engine layout Front, Transverse
Engine Model/Code 1KR-FE
Engine displacement 998 cm3
60.9 cu. in.
Number of cylinders 3
Engine configuration Inline
Cylinder Bore 71 mm
2.8 in.
Piston Stroke 84 mm
3.31 in.
Compression ratio 11:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.1 l
3.28 US qt | 2.73 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 4.7 l
4.97 US qt | 4.14 UK qt

Space, Volume and weights
Kerb Weight 950 kg
2094.39 lbs.
Max. weight 1430 kg
3152.61 lbs.
Max load 480 kg
1058.22 lbs.
Trunk (boot) space – minimum 286 l
10.1 cu. ft.
Fuel tank capacity 42 l
11.1 US gal | 9.24 UK gal
Dimensions
Length 3885 mm
152.95 in.
Width 1695 mm
66.73 in.
Height 1510 mm
59.45 in.
Wheelbase 2510 mm
98.82 in.
Front track 1460 mm
57.48 in.
Rear (Back) track 1445 mm
56.89 in.
Minimum turning circle (turning diameter) 9.4 m
30.84 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Torsion
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 175/70 R14
Wheel rims size 14
