Specifications: TVR Cerbera 4.3 i V8 (280 Hp) 1995, 1996, 1997, 1998, 1999, 2000

1996 TVR Cerbera - Photo 1

TVR Cerbera 4.3 i V8 (280 Hp) – Full specifications
General information
Brand TVR
Model Cerbera
Generation Cerbera
Modification (Engine) 4.3 i V8 (280 Hp)
Start of production 1995 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 2
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 3.9 kg/Hp, 254.5 Hp/tonne
Weight-to-torque ratio 2.8 kg/Nm, 361.8 Nm/tonne
Engine specs
Power 280 Hp @ 5500 rpm.
Power per litre 65.4 Hp/l
Torque 398 Nm @ 4000 rpm.
293.55 lb.-ft. @ 4000 rpm.
Engine layout Front, Longitudinal
Engine displacement 4280 cm3
261.18 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 94 mm
3.7 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 10:1
Number of valves per cylinder 2
Fuel injection system Single-point injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt

Space, Volume and weights
Kerb Weight 1100 kg
2425.08 lbs.
Fuel tank capacity 57 l
15.06 US gal | 12.54 UK gal
Dimensions
Length 4146 mm
163.23 in.
Width 1943 mm
76.5 in.
Height 1205 mm
47.44 in.
Wheelbase 2485 mm
97.83 in.
Front track 1460 mm
57.48 in.
Rear (Back) track 1460 mm
57.48 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Double wishbone
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/70 ZR16
