Specifications: Vauxhall Astra Mk V Convertible 2.0 (200 Hp) 2006, 2007, 2008, 2009, 2010, 2011

2006 Vauxhall Astra Mk V Convertible - Photo 1

Vauxhall Astra Mk V Convertible 2.0 (200 Hp) – Full specifications
General information
Brand Vauxhall
Model Astra
Generation Astra Mk V Convertible
Modification (Engine) 2.0 (200 Hp)
Start of production 2006 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Coupe – Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 13.4 l/100 km
17.6 US mpg
21.1 UK mpg
7.5 km/l
Fuel consumption (economy) – extra urban 7.3 l/100 km
32.2 US mpg
38.7 UK mpg
13.7 km/l
Fuel consumption (economy) – combined 9.5 l/100 km
24.8 US mpg
29.7 UK mpg
10.5 km/l
CO2 emissions 228 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.3 sec
Acceleration 0 – 62 mph 8.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.9 sec
Maximum speed 237 km/h
147.26 mph
Emission standard Euro 4
Weight-to-power ratio 8.2 kg/Hp, 121.6 Hp/tonne
Weight-to-torque ratio 6.3 kg/Nm, 159.3 Nm/tonne
Engine specs
Power 200 Hp @ 5400 rpm.
Power per litre 100.1 Hp/l
Torque 262 Nm @ 4200 rpm.
193.24 lb.-ft. @ 4200 rpm.
Engine layout Front, Transverse
Engine Model/Code Z20LER
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 8.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.7 l
8.14 US qt | 6.78 UK qt

Space, Volume and weights
Kerb Weight 1645 kg
3626.6 lbs.
Max. weight 1865 kg
4111.62 lbs.
Max load 220 kg
485.02 lbs.
Trunk (boot) space – minimum 205 l
7.24 cu. ft.
Trunk (boot) space – maximum 440 l
15.54 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Dimensions
Length 4476 mm
176.22 in.
Width 1759 mm
69.25 in.
Width including mirrors 2021 mm
79.57 in.
Height 1411 mm
55.55 in.
Wheelbase 2614 mm
102.91 in.
Front track 1491 mm
58.7 in.
Rear (Back) track 1481 mm
58.31 in.
Ride height (ground clearance) 130 mm
5.12 in.
Drag coefficient (Cd) 0.31
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Tires size 225/45 R17
Wheel rims size 17
