Specifications: Vauxhall Astra Mk V Estate 1.7 CDTi (80 Hp) 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011

2004 Vauxhall Astra Mk V Estate - Photo 1

Vauxhall Astra Mk V Estate 1.7 CDTi (80 Hp) – Full specifications
General information
Brand Vauxhall
Model Astra
Generation Astra Mk V Estate
Modification (Engine) 1.7 CDTi (80 Hp)
Start of production 2004 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – extra urban 4 l/100 km
58.8 US mpg
70.6 UK mpg
25 km/l
Fuel consumption (economy) – combined 4.8 l/100 km
49 US mpg
58.9 UK mpg
20.8 km/l
CO2 emissions 132 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.7 sec
Acceleration 0 – 62 mph 11.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.1 sec
Maximum speed 180 km/h
111.85 mph
Weight-to-power ratio 16.1 kg/Hp, 62 Hp/tonne
Weight-to-torque ratio 7.6 kg/Nm, 131 Nm/tonne
Engine specs
Power 80 Hp @ 4400 rpm.
Power per litre 47.4 Hp/l
Torque 169 Nm @ 1800 rpm.
124.65 lb.-ft. @ 1800 rpm.
Engine layout Front, Transverse
Engine Model/Code Z17DTL
Engine displacement 1686 cm3
102.89 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 18.4:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.8 l
7.19 US qt | 5.98 UK qt

Space, Volume and weights
Kerb Weight 1290 kg
2843.96 lbs.
Max. weight 1905 kg
4199.81 lbs.
Max load 615 kg
1355.84 lbs.
Trunk (boot) space – minimum 500 l
17.66 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Dimensions
Length 4515 mm
177.76 in.
Width 1753 mm
69.02 in.
Width including mirrors 2033 mm
80.04 in.
Height 1496 mm
58.9 in.
Wheelbase 2703 mm
106.42 in.
Front track 1488 mm
58.58 in.
Rear (Back) track 1488 mm
58.58 in.
Front overhang 871 mm
34.29 in.
Rear overhang 941 mm
37.05 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.32
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Tires size 195/65 R15
Wheel rims size 15
