Specifications: Vauxhall Cavalier Mk III CC 1.7 D (57 Hp) 1988, 1989

1988 Vauxhall Cavalier Mk III CC - Photo 1

Vauxhall Cavalier Mk III CC 1.7 D (57 Hp) – Full specifications
General information
Brand Vauxhall
Model Cavalier
Generation Cavalier Mk III CC
Modification (Engine) 1.7 D (57 Hp)
Start of production 1988 year
End of production 1989 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
Fuel consumption (economy) – extra urban 4.4 l/100 km
53.5 US mpg
64.2 UK mpg
22.7 km/l
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 20 sec
Acceleration 0 – 62 mph 20 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 19 sec
Maximum speed 152 km/h
94.45 mph
Weight-to-power ratio 19.2 kg/Hp, 52.1 Hp/tonne
Weight-to-torque ratio 10.4 kg/Nm, 95.9 Nm/tonne
Engine specs
Power 57 Hp @ 4600 rpm.
Power per litre 33.5 Hp/l
Torque 105 Nm @ 2400 rpm.
77.44 lb.-ft. @ 2400 rpm.
Engine layout Front, Transverse
Engine Model/Code 17D
Engine displacement 1700 cm3
103.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 79.5 mm
3.13 in.
Compression ratio 23:1
Number of valves per cylinder 2
Fuel injection system Precombustion chamber injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 4.75 l
5.02 US qt | 4.18 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.1 l
9.62 US qt | 8.01 UK qt

Space, Volume and weights
Kerb Weight 1095 kg
2414.06 lbs.
Max. weight 1610 kg
3549.44 lbs.
Max load 515 kg
1135.38 lbs.
Trunk (boot) space – minimum 460 l
16.24 cu. ft.
Trunk (boot) space – maximum 1290 l
45.56 cu. ft.
Fuel tank capacity 61 l
16.11 US gal | 13.42 UK gal
Dimensions
Length 4352 mm
171.34 in.
Width 1706 mm
67.17 in.
Height 1400 mm
55.12 in.
Wheelbase 2600 mm
102.36 in.
Front track 1420 mm
55.91 in.
Rear (Back) track 1423 mm
56.02 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 175/70 R14
Wheel rims size 14
