Specifications: Vauxhall Corsa B 1.5 TD (67 Hp) 1993, 1994, 1995, 1996, 1997

1993 Vauxhall Corsa B - Photo 1

Vauxhall Corsa B 1.5 TD (67 Hp) – Full specifications
General information
Brand Vauxhall
Model Corsa
Generation Corsa B
Modification (Engine) 1.5 TD (67 Hp)
Start of production 1993 year
End of production 1997 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3-5
Performance specs
Fuel consumption (economy) – urban 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel consumption (economy) – extra urban 4 l/100 km
58.8 US mpg
70.6 UK mpg
25 km/l
Fuel consumption (economy) – combined 5.7 l/100 km
41.3 US mpg
49.6 UK mpg
17.5 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 14 sec
Acceleration 0 – 62 mph 14 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.3 sec
Maximum speed 165 km/h
102.53 mph
Weight-to-power ratio 14.2 kg/Hp, 70.5 Hp/tonne
Weight-to-torque ratio 7.2 kg/Nm, 138.9 Nm/tonne
Engine specs
Power 67 Hp @ 4600 rpm.
Power per litre 45 Hp/l
Torque 132 Nm @ 2600 rpm.
97.36 lb.-ft. @ 2600 rpm.
Engine layout Front, Transverse
Engine Model/Code X15DT, T4EC1
Engine displacement 1488 cm3
90.8 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 76 mm
2.99 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 22:1
Number of valves per cylinder 2
Fuel injection system Precombustion chamber injection
Engine aspiration Turbocharger
Engine oil capacity 3.75 l
3.96 US qt | 3.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.3 l
6.66 US qt | 5.54 UK qt

Space, Volume and weights
Kerb Weight 950 kg
2094.39 lbs.
Max. weight 1445 kg
3185.68 lbs.
Max load 495 kg
1091.29 lbs.
Trunk (boot) space – minimum 260 l
9.18 cu. ft.
Trunk (boot) space – maximum 1050 l
37.08 cu. ft.
Fuel tank capacity 46 l
12.15 US gal | 10.12 UK gal
Dimensions
Length 3740 mm
147.24 in.
Width 1610 mm
63.39 in.
Height 1420 mm
55.91 in.
Wheelbase 2443 mm
96.18 in.
Front track 1387 mm
54.61 in.
Rear (Back) track 1388 mm
54.65 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Worm-reduction unit
Tires size 165/70 R13
Wheel rims size 5J x 13
