Specifications: Vauxhall Insignia I Hatchback 2.0i Turbo ecoTEC (220 Hp) AWD 2008, 2009, 2010, 2011, 2012, 2013

2008 Vauxhall Insignia I Hatchback - Photo 1

Vauxhall Insignia I Hatchback 2.0i Turbo ecoTEC (220 Hp) AWD – Full specifications
General information
Brand Vauxhall
Model Insignia
Generation Insignia I Hatchback
Modification (Engine) 2.0i Turbo ecoTEC (220 Hp) AWD
Start of production 2008 year
End of production 2013 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 13 l/100 km
18.1 US mpg
21.7 UK mpg
7.7 km/l
Fuel consumption (economy) – extra urban 7 l/100 km
33.6 US mpg
40.4 UK mpg
14.3 km/l
Fuel consumption (economy) – combined 9.2 l/100 km
25.6 US mpg
30.7 UK mpg
10.9 km/l
CO2 emissions 215 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.3 sec
Acceleration 0 – 62 mph 7.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.9 sec
Maximum speed 240 km/h
149.13 mph
Emission standard Euro 5
Weight-to-power ratio 7.5 kg/Hp, 132.7 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 211.1 Nm/tonne
Engine specs
Power 220 Hp @ 5300 rpm.
Power per litre 110.1 Hp/l
Torque 350 Nm @ 2000-4000 rpm.
258.15 lb.-ft. @ 2000-4000 rpm.
Engine layout Front, Transverse
Engine Model/Code A20NHT
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 9.3:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-scroll turbo, Intercooler
Valvetrain DOHC
Engine oil capacity 6 l
6.34 US qt | 5.28 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.3 l
7.71 US qt | 6.42 UK qt

Space, Volume and weights
Kerb Weight 1658 kg
3655.26 lbs.
Max. weight 2265 kg
4993.47 lbs.
Max load 607 kg
1338.21 lbs.
Trunk (boot) space – minimum 520 l
18.36 cu. ft.
Trunk (boot) space – maximum 1463 l
51.67 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Permitted trailer load with brakes (12%) 1900 kg
4188.78 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4830 mm
190.16 in.
Width 1856 mm
73.07 in.
Width including mirrors 2084 mm
82.05 in.
Height 1498 mm
58.98 in.
Wheelbase 2737 mm
107.76 in.
Front track 1585 mm
62.4 in.
Rear (Back) track 1585 mm
62.4 in.
Front overhang 1015 mm
39.96 in.
Rear overhang 1078 mm
42.44 in.
Ride height (ground clearance) 160 mm
6.3 in.
Drag coefficient (Cd) 0.27
Minimum turning circle (turning diameter) 10.97 m
35.99 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Power steering Hydraulic Steering
Tires size 225/55 R17
Wheel rims size 17
