Specifications: Vauxhall Tigra Mk II Roadster 1.4i 16V ECOTEC (90 Hp) Automatic 2004, 2005, 2006, 2007, 2008, 2009

2004 Vauxhall Tigra Mk II Roadster - Photo 1

Vauxhall Tigra Mk II Roadster 1.4i 16V ECOTEC (90 Hp) Automatic – Full specifications
General information
Brand Vauxhall
Model Tigra
Generation Tigra Mk II Roadster
Modification (Engine) 1.4i 16V ECOTEC (90 Hp) Automatic
Start of production 2004 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Roadster
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) – urban 8 l/100 km
29.4 US mpg
35.3 UK mpg
12.5 km/l
Fuel consumption (economy) – extra urban 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
CO2 emissions 146 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 13.4 sec
Acceleration 0 – 62 mph 13.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.7 sec
Maximum speed 178 km/h
110.6 mph
Emission standard Euro 4
Weight-to-power ratio 13.7 kg/Hp, 72.9 Hp/tonne
Weight-to-torque ratio 9.9 kg/Nm, 101.2 Nm/tonne
Engine specs
Power 90 Hp @ 5600 rpm.
Power per litre 66 Hp/l
Torque 125 Nm @ 4000 rpm.
92.2 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code Z14XEP
Engine displacement 1364 cm3
83.24 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 73.4 mm
2.89 in.
Piston Stroke 80.6 mm
3.17 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5 l
5.28 US qt | 4.4 UK qt

Space, Volume and weights
Kerb Weight 1235 kg
2722.71 lbs.
Max. weight 1450 kg
3196.7 lbs.
Max load 215 kg
473.99 lbs.
Trunk (boot) space – minimum 250 l
8.83 cu. ft.
Trunk (boot) space – maximum 440 l
15.54 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Dimensions
Length 3921 mm
154.37 in.
Width 1685 mm
66.34 in.
Width including mirrors 1905 mm
75 in.
Height 1364 mm
53.7 in.
Wheelbase 2491 mm
98.07 in.
Front track 1429 mm
56.26 in.
Rear (Back) track 1420 mm
55.91 in.
Minimum turning circle (turning diameter) 10.46 m
34.32 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 185/60 R15
Wheel rims size 6J x 15
