Specifications: Volkswagen Beetle Convertible (A5) 1.4 TSI (150 Hp) 2014, 2015, 2016

2013 Volkswagen Beetle Convertible (A5) - Photo 1

Volkswagen Beetle Convertible (A5) 1.4 TSI (150 Hp) – Full specifications
General information
Brand Volkswagen
Model Beetle
Generation Beetle Convertible (A5)
Modification (Engine) 1.4 TSI (150 Hp)
Start of production 2014 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 7.3 l/100 km
32.2 US mpg
38.7 UK mpg
13.7 km/l
Fuel consumption (economy) – extra urban 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
CO2 emissions 138 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.1 sec
Acceleration 0 – 62 mph 9.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.6 sec
Maximum speed 201 km/h
124.9 mph
Emission standard Euro 6
Weight-to-power ratio 9.6 kg/Hp, 104.6 Hp/tonne
Weight-to-torque ratio 5.7 kg/Nm, 174.3 Nm/tonne
Engine specs
Power 150 Hp @ 5000-6000 rpm.
Power per litre 107.9 Hp/l
Torque 250 Nm @ 1500-3500 rpm.
184.39 lb.-ft. @ 1500-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code CZDA
Engine displacement 1390 cm3
84.82 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1434 kg
3161.43 lbs.
Max. weight 1810 kg
3990.37 lbs.
Max load 376 kg
828.94 lbs.
Trunk (boot) space – minimum 225 l
7.95 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4278 mm
168.43 in.
Width 1808 mm
71.18 in.
Width including mirrors 2021 mm
79.57 in.
Height 1473 mm
57.99 in.
Wheelbase 2540 mm
100 in.
Front track 1578 mm
62.13 in.
Rear (Back) track 1554 mm
61.18 in.
Ride height (ground clearance) 136 mm
5.35 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Approach angle 13.6°
Departure angle 14.8°
Ramp-over (brakeover) angle 11°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 215/60 R16; 215/55 R17; 235/45 R18
Wheel rims size 6.5J x 16; 7J x 17; 8J x 18
