Specifications: Volkswagen Beetle Convertible (A5, facelift 2016) 1.2 TSI (105 Hp) DSG 2016, 2017, 2018

2016 Volkswagen Beetle Convertible (A5, facelift 2016) - Photo 1

Volkswagen Beetle Convertible (A5, facelift 2016) 1.2 TSI (105 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Beetle
Generation Beetle Convertible (A5, facelift 2016)
Modification (Engine) 1.2 TSI (105 Hp) DSG
Start of production 2016 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 6.2-6.3 l/100 km
37.9 – 37.3 US mpg
45.6 – 44.8 UK mpg
16.1 – 15.9 km/l
Fuel consumption (economy) – extra urban 4.7-4.8 l/100 km
50 – 49 US mpg
60.1 – 58.9 UK mpg
21.3 – 20.8 km/l
Fuel consumption (economy) – combined 5.3-5.4 l/100 km
44.4 – 43.6 US mpg
53.3 – 52.3 UK mpg
18.9 – 18.5 km/l
CO2 emissions 123-125 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.7 sec
Acceleration 0 – 62 mph 11.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.1 sec
Maximum speed 178 km/h
110.6 mph
Emission standard Euro 6
Weight-to-power ratio 12.8 kg/Hp, 78 Hp/tonne
Weight-to-torque ratio 7.7 kg/Nm, 130 Nm/tonne
Engine specs
Power 105 Hp @ 4500-5500 rpm.
Power per litre 87.7 Hp/l
Torque 175 Nm @ 1400-4000 rpm.
129.07 lb.-ft. @ 1400-4000 rpm.
Engine layout Front, Transverse
Engine Model/Code CBZB, CYVD
Engine displacement 1197 cm3
73.05 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71 mm
2.8 in.
Piston Stroke 75.6 mm
2.98 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.9 l
4.12 US qt | 3.43 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1346 kg
2967.42 lbs.
Max. weight 1820 kg
4012.41 lbs.
Max load 474 kg
1044.99 lbs.
Trunk (boot) space – minimum 225 l
7.95 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4288 mm
168.82 in.
Width 1825 mm
71.85 in.
Width including mirrors 2021 mm
79.57 in.
Height 1473 mm
57.99 in.
Wheelbase 2538 mm
99.92 in.
Front track 1570-1580 mm
61.81 – 62.2 in.
Rear (Back) track 1569-1579 mm
61.77 – 62.17 in.
Ride height (ground clearance) 136 mm
5.35 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R16
Wheel rims size 6.5J x 16
