Specifications: Volkswagen Bora (1J2) 1.9 TDI (115 Hp) 4MOTION 2000, 2001

1999 Volkswagen Bora (1J2) - Photo 1

Volkswagen Bora (1J2) 1.9 TDI (115 Hp) 4MOTION – Full specifications
General information
Brand Volkswagen
Model Bora
Generation Bora (1J2)
Modification (Engine) 1.9 TDI (115 Hp) 4MOTION
Start of production 2000 year
End of production 2001 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 8.1 l/100 km
29 US mpg
34.9 UK mpg
12.3 km/l
Fuel consumption (economy) – extra urban 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
Fuel consumption (economy) – combined 6.2 l/100 km
37.9 US mpg
45.6 UK mpg
16.1 km/l
CO2 emissions 167 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.1 sec
Acceleration 0 – 62 mph 11.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 192 km/h
119.3 mph
Emission standard Euro 3
Weight-to-power ratio 12.4 kg/Hp, 80.4 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 216.8 Nm/tonne
Engine specs
Power 115 Hp @ 4000 rpm.
Power per litre 60.7 Hp/l
Torque 310 Nm @ 1900 rpm.
228.64 lb.-ft. @ 1900 rpm.
Engine layout Front, Transverse
Engine Model/Code AJM, AUY
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 18:1
Number of valves per cylinder 2
Fuel injection system Pump-nozzle (Unit Injector)
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt

Space, Volume and weights
Kerb Weight 1430 kg
3152.61 lbs.
Max. weight 1970 kg
4343.11 lbs.
Max load 540 kg
1190.5 lbs.
Trunk (boot) space – minimum 340 l
12.01 cu. ft.
Trunk (boot) space – maximum 670 l
23.66 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1600 kg
3527.4 lbs.
Permitted trailer load without brakes 650 kg
1433 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4376 mm
172.28 in.
Width 1735 mm
68.31 in.
Width including mirrors 2018 mm
79.45 in.
Height 1446 mm
56.93 in.
Wheelbase 2519 mm
99.17 in.
Front track 1513 mm
59.57 in.
Rear (Back) track 1494 mm
58.82 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/55 R16
Wheel rims size 16
