Specifications: Volkswagen Bora Variant (1J6) 2.0 (115 Hp) 4MOTION 1999, 2000, 2001, 2002, 2003, 2004, 2005

1999 Volkswagen Bora Variant (1J6) - Photo 1

Volkswagen Bora Variant (1J6) 2.0 (115 Hp) 4MOTION – Full specifications
General information
Brand Volkswagen
Model Bora
Generation Bora Variant (1J6)
Modification (Engine) 2.0 (115 Hp) 4MOTION
Start of production 1999 year
End of production 2005 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 11.7 l/100 km
20.1 US mpg
24.1 UK mpg
8.5 km/l
Fuel consumption (economy) – extra urban 7 l/100 km
33.6 US mpg
40.4 UK mpg
14.3 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12 sec
Acceleration 0 – 62 mph 12 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.4 sec
Maximum speed 192 km/h
119.3 mph
Weight-to-power ratio 12.4 kg/Hp, 80.4 Hp/tonne
Weight-to-torque ratio 8.6 kg/Nm, 116.1 Nm/tonne
Engine specs
Power 115 Hp @ 5400 rpm.
Power per litre 58 Hp/l
Torque 166 Nm @ 3600 rpm.
122.44 lb.-ft. @ 3600 rpm.
Engine layout Front, Transverse
Engine Model/Code APK, AQY
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 10:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5 l
5.28 US qt | 4.4 UK qt

Space, Volume and weights
Kerb Weight 1430 kg
3152.61 lbs.
Max. weight 1960 kg
4321.06 lbs.
Max load 530 kg
1168.45 lbs.
Trunk (boot) space – minimum 360 l
12.71 cu. ft.
Trunk (boot) space – maximum 1370 l
48.38 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4409 mm
173.58 in.
Width 1735 mm
68.31 in.
Height 1485 mm
58.46 in.
Wheelbase 2515 mm
99.02 in.
Front track 1513 mm
59.57 in.
Rear (Back) track 1494 mm
58.82 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 15
