Specifications: Volkswagen Caddy Cargo V 1.5 TSI (116 Hp) 2024, 2025

2021 Volkswagen Caddy Cargo V - Photo 1

Volkswagen Caddy Cargo V 1.5 TSI (116 Hp) – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy Cargo V
Modification (Engine) 1.5 TSI (116 Hp)
Start of production May, 2024 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 2
Doors 4-5
Performance specs
Fuel consumption at Low speed (WLTP) 7.9 l/100 km
29.8 US mpg
35.8 UK mpg
12.7 km/l
Fuel consumption at Medium speed (WLTP) 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption at high speed (WLTP) 5.7 l/100 km
41.3 US mpg
49.6 UK mpg
17.5 km/l
Fuel consumption at very high speed (WLTP) 6.9 l/100 km
34.1 US mpg
40.9 UK mpg
14.5 km/l
Combined fuel consumption (WLTP) 6.5-6.6 l/100 km
36.2 – 35.6 US mpg
43.5 – 42.8 UK mpg
15.4 – 15.2 km/l
CO2 emissions (WLTP) 148-156 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.1 sec
Acceleration 0 – 62 mph 11.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 182 km/h
113.09 mph
Emission standard Euro 6 EA
Weight-to-power ratio 11.8 kg/Hp, 84.9 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 160.9 Nm/tonne
Engine specs
Power 116 Hp @ 5000-6000 rpm.
Power per litre 77.4 Hp/l
Torque 220 Nm @ 1500-3000 rpm.
162.26 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine displacement 1498 cm3
91.41 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 74.5 mm
2.93 in.
Piston Stroke 85.9 mm
3.38 in.
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1367-1403 kg
3013.72 – 3093.09 lbs.
Max. weight 2150 kg
4739.94 lbs.
Max load 747-783 kg
1646.85 – 1726.22 lbs.
Trunk (boot) space – maximum 3100 l
109.48 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1500 kg
3306.93 lbs.
Permitted trailer load with brakes (12%) 1400 kg
3086.47 lbs.
Permitted trailer load without brakes 710 kg
1565.28 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4500 mm
177.17 in.
Width 1855 mm
73.03 in.
Width including mirrors 2100 mm
82.68 in.
Height 1856 mm
73.07 in.
Wheelbase 2755 mm
108.46 in.
Front overhang 890 mm
35.04 in.
Rear overhang 855 mm
33.66 in.
Ride height (ground clearance) 160 mm
6.3 in.
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Approach angle 16.8°
Departure angle 18.7°
Ramp-over (brakeover) angle 14°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Rigid axle suspension, Trailing arm, Coil spring
Front brakes Ventilated discs, 312×25 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/60 R16; 215/55 R17
Wheel rims size 6.5J x 16; 6.5J x 17
