Specifications: Volkswagen Caddy III 1.9 TDI (105 Hp) DSG 2005, 2006, 2007, 2008, 2009, 2010

2004 Volkswagen Caddy III - Photo 1

Volkswagen Caddy III 1.9 TDI (105 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy III
Modification (Engine) 1.9 TDI (105 Hp) DSG
Start of production 2005 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 4-5
Performance specs
Fuel consumption (economy) – urban 8.3 l/100 km
28.3 US mpg
34 UK mpg
12 km/l
Fuel consumption (economy) – extra urban 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel consumption (economy) – combined 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
CO2 emissions 177 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 13.3 sec
Acceleration 0 – 62 mph 13.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.6 sec
Maximum speed 166 km/h
103.15 mph
Emission standard Euro 4
Weight-to-power ratio 14.4 kg/Hp, 69.5 Hp/tonne
Weight-to-torque ratio 6 kg/Nm, 165.5 Nm/tonne
Engine specs
Power 105 Hp @ 4000 rpm.
Power per litre 55.4 Hp/l
Torque 250 Nm @ 1900 rpm.
184.39 lb.-ft. @ 1900 rpm.
Engine layout Front, Transverse
Engine Model/Code EA188 / BJB
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 19:1
Number of valves per cylinder 2
Fuel injection system Pump-nozzle (Unit Injector)
Engine aspiration Turbocharger, Intercooler
Valvetrain SOHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1511-1677 kg
3331.18 – 3697.15 lbs.
Max. weight 2280 kg
5026.54 lbs.
Max load 603-769 kg
1329.39 – 1695.35 lbs.
Trunk (boot) space – minimum 190 l
6.71 cu. ft.
Trunk (boot) space – maximum 3020 l
106.65 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1500 kg
3306.93 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4405 mm
173.43 in.
Width 1794 mm
70.63 in.
Width including mirrors 2062 mm
81.18 in.
Height 1833 mm
72.17 in.
Wheelbase 2682 mm
105.59 in.
Front track 1537 mm
60.51 in.
Rear (Back) track 1531 mm
60.28 in.
Front overhang 880 mm
34.65 in.
Rear overhang 843 mm
33.19 in.
Ride height (ground clearance) 176 mm
6.93 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission DSG
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Rigid axle suspension, Transverse stabilizer, Leaf spring
Front brakes Ventilated discs, 280×22 mm
Rear brakes Disc, 260×12 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
