Specifications: Volkswagen Caddy III (facelift 2010) 1.6 TDI (102 Hp) 2010, 2011, 2012, 2013, 2014, 2015

2010 Volkswagen Caddy III (facelift 2010) - Photo 1

Volkswagen Caddy III (facelift 2010) 1.6 TDI (102 Hp) – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy III (facelift 2010)
Modification (Engine) 1.6 TDI (102 Hp)
Start of production 2010 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l
Fuel consumption (economy) – extra urban 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
Fuel consumption (economy) – combined 5.7 l/100 km
41.3 US mpg
49.6 UK mpg
17.5 km/l
CO2 emissions 149 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.9 sec
Acceleration 0 – 62 mph 12.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.3 sec
Maximum speed 168 km/h
104.39 mph
Emission standard Euro 5
Weight-to-power ratio 13.7 kg/Hp, 72.8 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 178.3 Nm/tonne
Engine specs
Power 102 Hp @ 4400 rpm.
Power per litre 63.8 Hp/l
Torque 250 Nm @ 1500-2500 rpm.
184.39 lb.-ft. @ 1500-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code CAYD
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 80.5 mm
3.17 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1402 kg
3090.88 lbs.
Max. weight 2159 kg
4759.78 lbs.
Max load 757 kg
1668.9 lbs.
Trunk (boot) space – minimum 918 l
32.42 cu. ft.
Trunk (boot) space – maximum 3200 l
113.01 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 700 kg
1543.24 lbs.
Dimensions
Length 4406 mm
173.46 in.
Width 1794 mm
70.63 in.
Width including mirrors 2062 mm
81.18 in.
Height 1823 mm
71.77 in.
Wheelbase 2681 mm
105.55 in.
Front overhang 878 mm
34.57 in.
Rear overhang 847 mm
33.35 in.
Ride height (ground clearance) 159 mm
6.26 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 205/55 R16; 205/50 R17
Wheel rims size 6J x 15; 6J x 16; 6J x 17
