Specifications: Volkswagen Caddy Maxi IV 1.4 TGI (110 Hp) CNG DSG 2015, 2016, 2017, 2018, 2019, 2020

2015 Volkswagen Caddy Maxi IV - Photo 1

Volkswagen Caddy Maxi IV 1.4 TGI (110 Hp) CNG DSG – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy Maxi IV
Modification (Engine) 1.4 TGI (110 Hp) CNG DSG
Start of production 2015 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 4-5
Performance specs
Fuel consumption (economy) – urban (CNG) (NEDC) 5.4-5.8 kg/100 km
Fuel consumption (economy) – extra urban (CNG) (NEDC) 3.8-4.3 kg/100 km
Fuel consumption (economy) – combined (CNG) (NEDC) 4.4-4.9 kg/100 km
CO2 emissions (CNG) (NEDC) 120-133 g/km
Fuel Type Petrol / CNG
Acceleration 0 – 100 km/h 13.7 sec
Acceleration 0 – 62 mph 13.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13 sec
Maximum speed 172 km/h
106.88 mph
Emission standard Euro 6
Weight-to-power ratio 14.6 kg/Hp, 68.3 Hp/tonne
Weight-to-torque ratio 8.1 kg/Nm, 124.1 Nm/tonne
Engine specs
Power 110 Hp @ 4800-6000 rpm.
Power per litre 78.9 Hp/l
Torque 200 Nm @ 1500-3500 rpm.
147.51 lb.-ft. @ 1500-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code EA211 / CPWA
Engine displacement 1395 cm3
85.13 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 74.5 mm
2.93 in.
Piston Stroke 80 mm
3.15 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.6 l
5.92 US qt | 4.93 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1611-1631 kg
3551.65 – 3595.74 lbs.
Max. weight 2280-2415 kg
5026.54 – 5324.16 lbs.
Max load 669-784 kg
1474.89 – 1728.42 lbs.
Trunk (boot) space – minimum 530 l
18.72 cu. ft.
Trunk (boot) space – maximum 4130 l
145.85 cu. ft.
Fuel tank capacity 13 l
3.43 US gal | 2.86 UK gal
CNG cylinder capacity 37 kg
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 1350 kg
2976.24 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4878 mm
192.05 in.
Width 1793 mm
70.59 in.
Width including mirrors 2079 mm
81.85 in.
Height 1868 mm
73.54 in.
Wheelbase 3006 mm
118.35 in.
Front overhang 879 mm
34.61 in.
Rear overhang 993 mm
39.09 in.
Ride height (ground clearance) 146 mm
5.75 in.
Minimum turning circle (turning diameter) 12.2 m
40.03 ft.
Approach angle 14.7°
Departure angle 20.2°
Ramp-over (brakeover) angle 12.6°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission DSG
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Rigid axle suspension, Transverse stabilizer, Leaf spring
Front brakes Ventilated discs, 312×25 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16
Wheel rims size 6J x 16
