Specifications: Volkswagen Caddy Maxi V 1.5 TSI (116 Hp) 2024, 2025

2021 Volkswagen Caddy Maxi V - Photo 1

Volkswagen Caddy Maxi V 1.5 TSI (116 Hp) – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy Maxi V
Modification (Engine) 1.5 TSI (116 Hp)
Start of production May, 2024 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 4-5
Performance specs
Fuel consumption at Low speed (WLTP) 8.3 l/100 km
28.3 US mpg
34 UK mpg
12 km/l
Fuel consumption at Medium speed (WLTP) 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
Fuel consumption at high speed (WLTP) 5.9 l/100 km
39.9 US mpg
47.9 UK mpg
16.9 km/l
Fuel consumption at very high speed (WLTP) 7.1 l/100 km
33.1 US mpg
39.8 UK mpg
14.1 km/l
Combined fuel consumption (WLTP) 6.7-6.8 l/100 km
35.1 – 34.6 US mpg
42.2 – 41.5 UK mpg
14.9 – 14.7 km/l
CO2 emissions (WLTP) 150-160 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.4 sec
Acceleration 0 – 62 mph 12.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.8 sec
Maximum speed 182 km/h
113.09 mph
Emission standard Euro 6e
Weight-to-power ratio 13.8 kg/Hp, 72.3 Hp/tonne
Weight-to-torque ratio 7.3 kg/Nm, 137.1 Nm/tonne
Engine specs
Power 116 Hp @ 5000 rpm.
Power per litre 77.4 Hp/l
Torque 220 Nm @ 1500-3000 rpm.
162.26 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine displacement 1498 cm3
91.41 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 74.5 mm
2.93 in.
Piston Stroke 85.9 mm
3.38 in.
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1605-1641 kg
3538.42 – 3617.79 lbs.
Max. weight 2350 kg
5180.86 lbs.
Max load 709-745 kg
1563.08 – 1642.44 lbs.
Trunk (boot) space – minimum 446 l
15.75 cu. ft.
Trunk (boot) space – maximum 3105 l
109.65 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Permitted trailer load with brakes (8%) 1500 kg
3306.93 lbs.
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4853 mm
191.06 in.
Width 1855 mm
73.03 in.
Width including mirrors 2100 mm
82.68 in.
Height 1836 mm
72.28 in.
Wheelbase 2970 mm
116.93 in.
Front overhang 890 mm
35.04 in.
Rear overhang 993 mm
39.09 in.
Ride height (ground clearance) 143 mm
5.63 in.
Minimum turning circle (turning diameter) 12.1 m
39.7 ft.
Approach angle 14.7°
Departure angle 15.9°
Ramp-over (brakeover) angle 11.8°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Rigid axle suspension, Trailing arm, Coil spring
Front brakes Ventilated discs, 312×25 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/65 R15; 205/60 R16; 215/55 R17; 225/45 R18
Wheel rims size 6J x 15; 6.5J x 16; 6.5J x 17; 7J x 18
