Specifications: Volkswagen Caddy Panel Van IV 2.0 TDI (102 Hp) 2015, 2016, 2017, 2018

2015 Volkswagen Caddy Panel Van IV - Photo 1

Volkswagen Caddy Panel Van IV 2.0 TDI (102 Hp) – Full specifications
General information
Brand Volkswagen
Model Caddy
Generation Caddy Panel Van IV
Modification (Engine) 2.0 TDI (102 Hp)
Start of production June, 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 2
Doors 4
Performance specs
Fuel consumption (economy) – urban 5.5 l/100 km
42.8 US mpg
51.4 UK mpg
18.2 km/l
Fuel consumption (economy) – extra urban 4 l/100 km
58.8 US mpg
70.6 UK mpg
25 km/l
Fuel consumption (economy) – combined 4.6 l/100 km
51.1 US mpg
61.4 UK mpg
21.7 km/l
CO2 emissions 120 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 12 sec
Acceleration 0 – 62 mph 12 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.4 sec
Maximum speed 172 km/h
106.88 mph
Emission standard Euro 6
Weight-to-power ratio 13.7 kg/Hp, 73 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 179 Nm/tonne
Engine specs
Power 102 Hp @ 2900-4000 rpm.
Power per litre 51.8 Hp/l
Torque 250 Nm @ 1300-2800 rpm.
184.39 lb.-ft. @ 1300-2800 rpm.
Engine layout Front, Transverse
Engine Model/Code CUUD, DFSD
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1397-1419 kg
3079.86 – 3128.36 lbs.
Max. weight 2141 kg
4720.1 lbs.
Max load 722-744 kg
1591.74 – 1640.24 lbs.
Trunk (boot) space – maximum 3200 l
113.01 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
AdBlue tank 9 l
2.38 US gal | 1.98 UK gal
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 680 kg
1499.14 lbs.
Dimensions
Length 4408 mm
173.54 in.
Width 1793 mm
70.59 in.
Width including mirrors 2065 mm
81.3 in.
Height 1823 mm
71.77 in.
Wheelbase 2682 mm
105.59 in.
Front overhang 879 mm
34.61 in.
Rear overhang 847 mm
33.35 in.
Ride height (ground clearance) 166 mm
6.54 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
