| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Caravelle |
| Generation | Caravelle (T4, facelift 1996) |
| Modification (Engine) | 1.9 TD (68 Hp) |
| Start of production | 1996 year |
| End of production | 2003 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 6-9 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 7.2 l/100 km 32.7 US mpg 39.2 UK mpg 13.9 km/l |
| Fuel consumption (economy) – combined (NEDC) | 8.3 l/100 km 28.3 US mpg 34 UK mpg 12 km/l |
| CO2 emissions (NEDC) | 224 g/km |
| Fuel Type | Diesel |
| Maximum speed | 132 km/h 82.02 mph |
| Weight-to-power ratio | 23.9 kg/Hp, 41.8 Hp/tonne |
| Weight-to-torque ratio | 11.6 kg/Nm, 86.2 Nm/tonne |
| Engine specs | |
| Power | 68 Hp @ 3700 rpm. |
| Power per litre | 35.9 Hp/l |
| Torque | 140 Nm @ 2000-3000 rpm. 103.26 lb.-ft. @ 2000-3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | ABL |
| Engine displacement | 1896 cm3 115.7 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm 3.13 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 22.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Turbocharger |
| Valvetrain | SOHC |
| Engine oil capacity | 5 l 5.28 US qt | 4.4 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9 l 9.51 US qt | 7.92 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1625 kg 3582.51 lbs. |
| Max. weight | 2575-2785 kg 5676.9 – 6139.87 lbs. |
| Max load | 950-1160 kg 2094.39 – 2557.36 lbs. |
| Trunk (boot) space – maximum | 5400 l 190.7 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 700 kg 1543.24 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4789 mm 188.54 in. |
| Width | 1840 mm 72.44 in. |
| Width including mirrors | 2175 mm 85.63 in. |
| Height | 1940 mm 76.38 in. |
| Wheelbase | 2920 mm 114.96 in. |
| Front track | 1589 mm 62.56 in. |
| Rear (Back) track | 1554 mm 61.18 in. |
| Front overhang | 968 mm 38.11 in. |
| Rear overhang | 901 mm 35.47 in. |
| Ride height (ground clearance) | 180 mm 7.09 in. |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Wading depth | 350 mm 13.78 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent torsion bar, double wishbone, Transverse stabilizer |
| Rear suspension | Independent coil spring, Trailing arm |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/70 R15; 205/65 R15 |
| Wheel rims size | 6J x 15 |
