| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Caravelle |
| Generation | Caravelle (T6.1, facelift 2019) |
| Modification (Engine) | 2.0 TDI (150 Hp) 4MOTION DSG |
| Start of production | 2020 year |
| End of production | 2022 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 4-9 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 9.7-10.3 l/100 km 24.2 – 22.8 US mpg 29.1 – 27.4 UK mpg 10.3 – 9.7 km/l |
| Fuel consumption at Medium speed (WLTP) | 7.9-8.9 l/100 km 29.8 – 26.4 US mpg 35.8 – 31.7 UK mpg 12.7 – 11.2 km/l |
| Fuel consumption at high speed (WLTP) | 6.8-7.5 l/100 km 34.6 – 31.4 US mpg 41.5 – 37.7 UK mpg 14.7 – 13.3 km/l |
| Fuel consumption at very high speed (WLTP) | 8.1-8.9 l/100 km 29 – 26.4 US mpg 34.9 – 31.7 UK mpg 12.3 – 11.2 km/l |
| Combined fuel consumption (WLTP) | 7.9-8.7 l/100 km 29.8 – 27 US mpg 35.8 – 32.5 UK mpg 12.7 – 11.5 km/l |
| CO2 emissions (WLTP) | 206-228 g/km |
| Fuel consumption (economy) – urban (NEDC, WLTP equivalent) | 7.4-7.9 l/100 km 31.8 – 29.8 US mpg 38.2 – 35.8 UK mpg 13.5 – 12.7 km/l |
| Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) | 6.3-6.5 l/100 km 37.3 – 36.2 US mpg 44.8 – 43.5 UK mpg 15.9 – 15.4 km/l |
| Fuel consumption (economy) – combined (NEDC, WLTP equivalent) | 6.8-7 l/100 km 34.6 – 33.6 US mpg 41.5 – 40.4 UK mpg 14.7 – 14.3 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 179-185 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12.5 sec |
| Acceleration 0 – 62 mph | 12.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.9 sec |
| Maximum speed | 179 km/h 111.23 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 14.3 kg/Hp, 69.7 Hp/tonne |
| Weight-to-torque ratio | 6.3 kg/Nm, 158.1 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 3250-3750 rpm. |
| Power per litre | 76.2 Hp/l |
| Torque | 340 Nm @ 1500-3000 rpm. 250.77 lb.-ft. @ 1500-3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA288MAR / DNAA |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7.4 l 7.82 US qt | 6.51 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2151-2404 kg 4742.14 – 5299.91 lbs. |
| Max. weight | 3080-3200 kg 6790.24 – 7054.79 lbs. |
| Max load | 796-929 kg 1754.88 – 2048.09 lbs. |
| Trunk (boot) space – maximum | 5800 l 204.83 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| AdBlue tank | 22 l 5.81 US gal | 4.84 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2220 kg 4894.26 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4904 mm 193.07 in. |
| Width | 1904 mm 74.96 in. |
| Width including mirrors | 2297 mm 90.43 in. |
| Height | 1970-1990 mm 77.56 – 78.35 in. |
| Wheelbase | 3000 mm 118.11 in. |
| Front overhang | 906 mm 35.67 in. |
| Rear overhang | 998 mm 39.29 in. |
| Ride height (ground clearance) | 193-201 mm 7.6 – 7.91 in. |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Approach angle | 21.2° |
| Departure angle | 16.2° |
| Ramp-over (brakeover) angle | 13.7° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 7 gears, automatic transmission DSG |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent coil spring, Wishbone, Transverse stabilizer |
| Front brakes | Ventilated discs, 308×29.5 mm |
| Rear brakes | Ventilated discs, 294×22 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/65 R16; 215/65 R16; 215/60 R17; 235/55 R17; 255/45 R18 |
| Wheel rims size | 6.5J x 16; 7J x 17; 8J x 18 |
