Specifications: Volkswagen CC I (facelift 2012) 2.0 TDI (140 Hp) DSG SCR 2012, 2013, 2014, 2015

2012 Volkswagen CC I (facelift 2012) - Photo 1

Volkswagen CC I (facelift 2012) 2.0 TDI (140 Hp) DSG SCR – Full specifications
General information
Brand Volkswagen
Model Passat CC
Generation CC I (facelift 2012)
Modification (Engine) 2.0 TDI (140 Hp) DSG SCR
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 4
Performance specs
Fuel consumption (economy) – urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – extra urban 4.5 l/100 km
52.3 US mpg
62.8 UK mpg
22.2 km/l
Fuel consumption (economy) – combined 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
CO2 emissions 134 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.8 sec
Acceleration 0 – 62 mph 9.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.3 sec
Maximum speed 212 km/h
131.73 mph
Emission standard Euro 5
Weight-to-power ratio 10.6 kg/Hp, 94 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 214.9 Nm/tonne
Engine specs
Power 140 Hp @ 4200 rpm.
Power per litre 71.1 Hp/l
Torque 320 Nm @ 1750-2500 rpm.
236.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code CBAB, CFFB
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1489 kg
3282.68 lbs.
Max. weight 1990 kg
4387.2 lbs.
Max load 501 kg
1104.52 lbs.
Trunk (boot) space – minimum 532 l
18.79 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1900 kg
4188.78 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4802 mm
189.06 in.
Width 1855 mm
73.03 in.
Width including mirrors 2090 mm
82.28 in.
Height 1417 mm
55.79 in.
Wheelbase 2711 mm
106.73 in.
Front track 1552 mm
61.1 in.
Rear (Back) track 1559 mm
61.38 in.
Ride height (ground clearance) 124 mm
4.88 in.
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Approach angle 12.6°
Departure angle 12.6°
Ramp-over (brakeover) angle 9.9°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission DSG
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 235/45 R17
Wheel rims size 8J x 17
