Specifications: Volkswagen CC I (facelift 2012) 2.0 TDI (184 Hp) 2015, 2016

2012 Volkswagen CC I (facelift 2012) - Photo 1

Volkswagen CC I (facelift 2012) 2.0 TDI (184 Hp) – Full specifications
General information
Brand Volkswagen
Model Passat CC
Generation CC I (facelift 2012)
Modification (Engine) 2.0 TDI (184 Hp)
Start of production April, 2015 year
End of production November, 2016 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 4
Performance specs
Fuel consumption (economy) – urban 5.9-6.0 l/100 km
39.9 – 39.2 US mpg
47.9 – 47.1 UK mpg
16.9 – 16.7 km/l
Fuel consumption (economy) – extra urban 4.3-4.4 l/100 km
54.7 – 53.5 US mpg
65.7 – 64.2 UK mpg
23.3 – 22.7 km/l
Fuel consumption (economy) – combined 4.9-5.0 l/100 km
48 – 47 US mpg
57.6 – 56.5 UK mpg
20.4 – 20 km/l
CO2 emissions 127-130 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.1 sec
Acceleration 0 – 62 mph 8.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.7 sec
Maximum speed 234 km/h
145.4 mph
Emission standard Euro 6
Weight-to-power ratio 8.2 kg/Hp, 121.5 Hp/tonne
Weight-to-torque ratio 4 kg/Nm, 250.8 Nm/tonne
Engine specs
Power 184 Hp @ 3500-4000 rpm.
Power per litre 93.5 Hp/l
Torque 380 Nm @ 1750-3250 rpm.
280.27 lb.-ft. @ 1750-3250 rpm.
Engine layout Front, Transverse
Engine Model/Code CUWA, CUXA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1515 kg
3340 lbs.
Max. weight 2010 kg
4431.29 lbs.
Max load 495 kg
1091.29 lbs.
Trunk (boot) space – minimum 532 l
18.79 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4802 mm
189.06 in.
Width 1855 mm
73.03 in.
Width including mirrors 2090 mm
82.28 in.
Height 1417 mm
55.79 in.
Wheelbase 2711 mm
106.73 in.
Front track 1552 mm
61.1 in.
Rear (Back) track 1559 mm
61.38 in.
Ride height (ground clearance) 124 mm
4.88 in.
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/40 R18
Wheel rims size 8J x 18
