Specifications: Volkswagen Golf IV 1.9 TDI (110 Hp) Automatic 1997, 1998, 1999, 2000, 2001

1998 Volkswagen Golf IV - Photo 1

Volkswagen Golf IV 1.9 TDI (110 Hp) Automatic – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf IV
Modification (Engine) 1.9 TDI (110 Hp) Automatic
Start of production 1997 year
End of production 2001 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3-5
Performance specs
Fuel consumption (economy) – urban 7 l/100 km
33.6 US mpg
40.4 UK mpg
14.3 km/l
Fuel consumption (economy) – extra urban 4.8 l/100 km
49 US mpg
58.9 UK mpg
20.8 km/l
Fuel consumption (economy) – combined 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.9 sec
Acceleration 0 – 62 mph 11.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.3 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 3
Weight-to-power ratio 11 kg/Hp, 90.5 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 193.4 Nm/tonne
Engine specs
Power 110 Hp @ 4150 rpm.
Power per litre 58 Hp/l
Torque 235 Nm @ 1900 rpm.
173.33 lb.-ft. @ 1900 rpm.
Engine layout Front, Transverse
Engine Model/Code AHF, ASV
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 19.5:1
Number of valves per cylinder 2
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt

Space, Volume and weights
Kerb Weight 1215 kg
2678.62 lbs.
Max. weight 1750 kg
3858.09 lbs.
Max load 535 kg
1179.47 lbs.
Trunk (boot) space – minimum 330 l
11.65 cu. ft.
Trunk (boot) space – maximum 1185 l
41.85 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4149 mm
163.35 in.
Width 1735 mm
68.31 in.
Height 1439 mm
56.65 in.
Wheelbase 2511 mm
98.86 in.
Front track 1513 mm
59.57 in.
Rear (Back) track 1494 mm
58.82 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
