Specifications: Volkswagen Golf IV Cabrio 1.8i (75 Hp) 1998, 1999, 2000

1998 Volkswagen Golf IV Cabrio - Photo 1

Volkswagen Golf IV Cabrio 1.8i (75 Hp) – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf IV Cabrio
Modification (Engine) 1.8i (75 Hp)
Start of production April, 1998 year
End of production October, 2000 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 11 l/100 km
21.4 US mpg
25.7 UK mpg
9.1 km/l
Fuel consumption (economy) – extra urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 15.5 sec
Acceleration 0 – 62 mph 15.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 14.7 sec
Maximum speed 160 km/h
99.42 mph
Weight-to-power ratio 15.4 kg/Hp, 64.9 Hp/tonne
Weight-to-torque ratio 8.3 kg/Nm, 121.2 Nm/tonne
Engine specs
Power 75 Hp @ 5000 rpm.
Power per litre 42.1 Hp/l
Torque 140 Nm @ 2500 rpm.
103.26 lb.-ft. @ 2500 rpm.
Engine layout Front, Transverse
Engine Model/Code ADZ, ANP, AAM, ANN
Engine displacement 1781 cm3
108.68 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 9:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.5 l
5.81 US qt | 4.84 UK qt

Space, Volume and weights
Kerb Weight 1155 kg
2546.34 lbs.
Max. weight 1580 kg
3483.3 lbs.
Max load 425 kg
936.96 lbs.
Trunk (boot) space – minimum 270 l
9.53 cu. ft.
Trunk (boot) space – maximum 448 l
15.82 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4081 mm
160.67 in.
Width 1695 mm
66.73 in.
Height 1425 mm
56.1 in.
Wheelbase 2472 mm
97.32 in.
Front track 1464 mm
57.64 in.
Rear (Back) track 1428 mm
56.22 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 185/60 R14
Wheel rims size 14
