Specifications: Volkswagen Golf V Plus 2.0 TDI (140 Hp) DSG 2005, 2006, 2007, 2008

2004 Volkswagen Golf V Plus - Photo 1

Volkswagen Golf V Plus 2.0 TDI (140 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf V Plus
Modification (Engine) 2.0 TDI (140 Hp) DSG
Start of production November, 2005 year
End of production November, 2008 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.2 l/100 km
28.7 US mpg
34.4 UK mpg
12.2 km/l
Fuel consumption (economy) – extra urban 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
Fuel consumption (economy) – combined 6.2 l/100 km
37.9 US mpg
45.6 UK mpg
16.1 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.7 sec
Acceleration 0 – 62 mph 9.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.2 sec
Maximum speed 200 km/h
124.27 mph
Weight-to-power ratio 10.2 kg/Hp, 98.2 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 224.4 Nm/tonne
Engine specs
Power 140 Hp @ 4000 rpm.
Power per litre 71.1 Hp/l
Torque 320 Nm @ 1750 rpm.
236.02 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code EA188 / BKD
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 18.5:1
Number of valves per cylinder 4
Fuel injection system Pump-nozzle (Unit Injector)
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1426 kg
3143.79 lbs.
Trunk (boot) space – minimum 395 l
13.95 cu. ft.
Trunk (boot) space – maximum 1450 l
51.21 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4206 mm
165.59 in.
Width 1759 mm
69.25 in.
Height 1580 mm
62.2 in.
Wheelbase 2578 mm
101.5 in.
Front track 1539 mm
60.59 in.
Rear (Back) track 1528 mm
60.16 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 195/65 R15V
Wheel rims size 6J x 15
