Specifications: Volkswagen Golf VI (3-door) GTI 2.0 TSI (210 Hp) 2009, 2010, 2011, 2012

2009 Volkswagen Golf VI (3-door) - Photo 1

Volkswagen Golf VI (3-door) GTI 2.0 TSI (210 Hp) – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf VI (3-door)
Modification (Engine) GTI 2.0 TSI (210 Hp)
Start of production March, 2009 year
End of production 2012 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 10 l/100 km
23.5 US mpg
28.2 UK mpg
10 km/l
Fuel consumption (economy) – extra urban 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel consumption (economy) – combined 7.3 l/100 km
32.2 US mpg
38.7 UK mpg
13.7 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.9 sec
Acceleration 0 – 62 mph 6.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.6 sec
Maximum speed 240 km/h
149.13 mph
Emission standard Euro 5
Weight-to-power ratio 6.3 kg/Hp, 159.3 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 212.4 Nm/tonne
Engine specs
Power 210 Hp @ 6200 rpm.
Power per litre 105.8 Hp/l
Torque 280 Nm @ 1800 rpm.
206.52 lb.-ft. @ 1800 rpm.
Engine layout Front, Transverse
Engine Model/Code CCZB
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1318 kg
2905.69 lbs.
Max. weight 1870 kg
4122.64 lbs.
Max load 552 kg
1216.95 lbs.
Trunk (boot) space – minimum 350 l
12.36 cu. ft.
Trunk (boot) space – maximum 1305 l
46.09 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4213 mm
165.87 in.
Width 1786 mm
70.31 in.
Height 1407 mm
55.39 in.
Wheelbase 2578 mm
101.5 in.
Front track 1533 mm
60.35 in.
Rear (Back) track 1514 mm
59.61 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/45 R17
Wheel rims size 7.5 J x 17
