Specifications: Volkswagen Golf VII (5-door) 1.0 TSI (115 Hp) BlueMotion DSG 2015, 2016

2013 Volkswagen Golf VII (5-door) - Photo 1

Volkswagen Golf VII (5-door) 1.0 TSI (115 Hp) BlueMotion DSG – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf VII (5-door)
Modification (Engine) 1.0 TSI (115 Hp) BlueMotion DSG
Start of production April, 2015 year
End of production December, 2016 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
Fuel consumption (economy) – extra urban 3.8 l/100 km
61.9 US mpg
74.3 UK mpg
26.3 km/l
Fuel consumption (economy) – combined 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
CO2 emissions 99 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.7 sec
Acceleration 0 – 62 mph 9.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.2 sec
Maximum speed 204 km/h
126.76 mph
Emission standard Euro 6
Weight-to-power ratio 10.1 kg/Hp, 99.3 Hp/tonne
Weight-to-torque ratio 5.8 kg/Nm, 172.7 Nm/tonne
Engine specs
Power 115 Hp @ 5000-5500 rpm.
Power per litre 115.1 Hp/l
Torque 200 Nm @ 2000-3500 rpm.
147.51 lb.-ft. @ 2000-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code CHZD
Engine displacement 999 cm3
60.96 cu. in.
Number of cylinders 3
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1158 kg
2552.95 lbs.
Max. weight 1730 kg
3814 lbs.
Max load 572 kg
1261.04 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1270 l
44.85 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1300 kg
2866.01 lbs.
Permitted trailer load with brakes (12%) 1000 kg
2204.62 lbs.
Permitted trailer load without brakes 610 kg
1344.82 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4255 mm
167.52 in.
Width 1799 mm
70.83 in.
Width including mirrors 2027 mm
79.8 in.
Height 1452 mm
57.17 in.
Wheelbase 2637 mm
103.82 in.
Front track 1549 mm
60.98 in.
Rear (Back) track 1520 mm
59.84 in.
Ride height (ground clearance) 142 mm
5.59 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 205/55 R16
Wheel rims size 6J x 15; 6.5J x 16
