Specifications: Volkswagen Golf VII (5-door, facelift 2017) 1.5 TSI ACT (150 Hp) 2017, 2018, 2019

2017 Volkswagen Golf VII (5-door, facelift 2017) - Photo 1

Volkswagen Golf VII (5-door, facelift 2017) 1.5 TSI ACT (150 Hp) – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf VII (5-door, facelift 2017)
Modification (Engine) 1.5 TSI ACT (150 Hp)
Start of production March, 2017 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.7-6.8 l/100 km
35.1 – 34.6 US mpg
42.2 – 41.5 UK mpg
14.9 – 14.7 km/l
Fuel consumption (economy) – extra urban 4.4-4.6 l/100 km
53.5 – 51.1 US mpg
64.2 – 61.4 UK mpg
22.7 – 21.7 km/l
Fuel consumption (economy) – combined 5.2-5.4 l/100 km
45.2 – 43.6 US mpg
54.3 – 52.3 UK mpg
19.2 – 18.5 km/l
CO2 emissions 119-123 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.3 sec
Acceleration 0 – 62 mph 8.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.9 sec
Maximum speed 216 km/h
134.22 mph
Emission standard Euro 6d-TEMP
Weight-to-power ratio 8.8 kg/Hp, 113.6 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 189.4 Nm/tonne
Engine specs
Power 150 Hp
Power per litre 100.1 Hp/l
Torque 250 Nm @ 1500-3500 rpm.
184.39 lb.-ft. @ 1500-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code EA211evo / DADA
Engine displacement 1498 cm3
91.41 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Cylinder deactivation system

Space, Volume and weights
Kerb Weight 1320 kg
2910.1 lbs.
Max. weight 1810 kg
3990.37 lbs.
Max load 490 kg
1080.27 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1270 l
44.85 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 660 kg
1455.05 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4258 mm
167.64 in.
Width 1790-1799 mm
70.47 – 70.83 in.
Width including mirrors 2027 mm
79.8 in.
Height 1492 mm
58.74 in.
Wheelbase 2620 mm
103.15 in.
Front track 1533-1549 mm
60.35 – 60.98 in.
Rear (Back) track 1504-1521 mm
59.21 – 59.88 in.
Ride height (ground clearance) 142 mm
5.59 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/50 R17; 225/45 R17
Wheel rims size 6J x 17; 7J x 17
