Specifications: Volkswagen Golf VII Variant 1.8 TSI (170 Hp) 2014, 2015, 2016, 2017

2013 Volkswagen Golf VII Variant - Photo 1

Volkswagen Golf VII Variant 1.8 TSI (170 Hp) – Full specifications
General information
Brand Volkswagen
Model Golf
Generation Golf VII Variant
Modification (Engine) 1.8 TSI (170 Hp)
Start of production 2014 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (EPA) 9.4 l/100 km
25 US mpg
30.1 UK mpg
10.6 km/l
Fuel consumption (economy) – extra urban (EPA) 6.5-6.7 l/100 km
36.2 – 35.1 US mpg
43.5 – 42.2 UK mpg
15.4 – 14.9 km/l
Fuel consumption (economy) – combined (EPA) 8.1-8.4 l/100 km
29 – 28 US mpg
34.9 – 33.6 UK mpg
12.3 – 11.9 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 8.2 kg/Hp, 122.4 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 180 Nm/tonne
Engine specs
Power 170 Hp @ 4500 rpm.
Power per litre 94.5 Hp/l
Torque 250 Nm @ 1600 rpm.
184.39 lb.-ft. @ 1600 rpm.
Engine layout Front, Transverse
Engine Model/Code EA888 / CXBA, CNSA
Engine displacement 1798 cm3
109.72 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 84.1 mm
3.31 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.7 l
6.02 US qt | 5.02 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1389 kg
3062.22 lbs.
Max. weight 1911 kg
4213.03 lbs.
Max load 522 kg
1150.81 lbs.
Trunk (boot) space – minimum 605 l
21.37 cu. ft.
Trunk (boot) space – maximum 1620 l
57.21 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Dimensions
Length 4562 mm
179.61 in.
Width 1799 mm
70.83 in.
Width including mirrors 2027 mm
79.8 in.
Height 1481 mm
58.31 in.
Wheelbase 2630 mm
103.54 in.
Front track 1549 mm
60.98 in.
Rear (Back) track 1520 mm
59.84 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 287×25 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 225/45 R17; 225/40 R18
Wheel rims size 6J x 15; 7J x 17; 7.5J x 18
