Specifications: Volkswagen ID.7 Pro S 91 kWh (286 Hp) 2024, 2025

2024 Volkswagen ID.7 - Photo 1

Volkswagen ID.7 Pro S 91 kWh (286 Hp) – Full specifications
General information
Brand Volkswagen
Model ID.7
Generation ID.7
Modification (Engine) Pro S 91 kWh (286 Hp)
Start of production June, 2024 year
Powertrain Architecture BEV (Electric Vehicle)
Body type Fastback
Seats 5
Doors 5
Performance specs
Fuel Type Electricity
Acceleration 0 – 100 km/h 6.6 sec
Acceleration 0 – 62 mph 6.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.3 sec
Maximum speed 180 km/h, Electronically limited
111.85 mph
Weight-to-power ratio 7.5 kg/Hp, 132.7 Hp/tonne
Weight-to-torque ratio 4 kg/Nm, 252.9 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 91 kWh
Net (usable) battery capacity 86 kWh
Battery voltage 383 V
Battery technology Lithium nickel manganese cobalt oxides (Li-NMC)
Battery location Below the floor
All-electric range (WLTP) 709 km
440.55 mi
Average Energy consumption (WLTP) 13.6 kWh/100 km

21.89 kWh/100 mi
154 MPGe
7.4 km/kWh
4.6 mi/kWh
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor power 286 Hp
Electric motor Torque 545 Nm

401.97 lb.-ft.
Electric motor model/code APP550
Electric motor location Rear axle, Transverse
Electric motor type Synchronous
System power 286 Hp
System torque 545 Nm
401.97 lb.-ft.

Space, Volume and weights
Kerb Weight 2155 kg
4750.96 lbs.
Max. weight 2690 kg
5930.43 lbs.
Max load 535 kg
1179.47 lbs.
Trunk (boot) space – minimum 532 l
18.79 cu. ft.
Trunk (boot) space – maximum 1586 l
56.01 cu. ft.
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1200 kg
2645.55 lbs.
Permitted trailer load with brakes (12%) 1000 kg
2204.62 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4961 mm
195.31 in.
Width 1862 mm
73.31 in.
Width including mirrors 2141 mm
84.29 in.
Height 1536 mm
60.47 in.
Wheelbase 2971 mm
116.97 in.
Front track 1588-1598 mm
62.52 – 62.91 in.
Rear (Back) track 1557-1569 mm
61.3 – 61.77 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Approach angle 14.2°
Departure angle 13.9°
Ramp-over (brakeover) angle 9.3°
Drivetrain, brakes and suspension specs
Drivetrain Architecture One electric motor drives the rear wheels.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 1 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size Front wheel tires: 235/50 R19; 235/45 R20
Rear wheel tires: 255/45 R19; 255/40 R20
Wheel rims size Front wheel rims: 8J x 19; 8.5J x 20
Rear wheel rims: 8.5J x 19; 9.5J x 20
